ZOTO For transformer 100% guarantee quality Enamelled aluminium flat wire

1.Introduction: The annealed conductor of kraft paper wrapped wire is extruded or dawn from oil-free copper rod or electrical round aluminum rod with certain specification mould. Then the copper or aluminum conductor is wrapped with two layers’ or more than two layers’ insulation paper including telephone paper, cable paper, high voltage paper, turn-to turn insulation paper. The product is widely applied in oil-immersed transformers and other similar electrical instruments. The electrical bare copper or aluminum wire with extrusion process is the ideal material for kraft paper wrapped copper or aluminum wire.

2.Standard: GB/T 7672-2008

3.Production Range:

  Aluminum Rectangular Wire

  Narrow border size a: 1.00-8.00mm

  Wide border size b: 3.00-25.00mm

  Copper Rectangular Wire

  Narrow border size a: 0.90-5.60mm

  Wide border size b: 2.00-16.00mm

  Copper or Aluminum Round Wire

  Diameter: Φ1.7-Φ8.0mm

  If specification is out of range, please don’t hesitate to contact us.

4.Material:

Aluminum rectangular wire should conform to GB5584.3-2009, the resistivity (20℃) is no more than 0.0280Ωmm²/m

Copper rectangular wire should conform to GB5584.2-2009, the resistivity (20℃) is no more than 0.01724Ωmm²/m

5.Thickness of kraft paper wrapped round or rectangular wire should conform to the following table or mutual consultation between supply and demand requirements:

Kraft Paper Wrapped Round Wire       Unit: mm

Note: If thickness is between two specification, please take the deviation corresponding to large size.

Kraft Paper Wrapped Rectangular Wire       Unit: mm

6Bending Standard of kraft paper wrapped Wire

Kraft Paper Wrapped Round Wire             Unit: mm

Kraft paper wrapped rectangular wire     Unit: mm

1.Q:Are you a factory or trading company?
A:We are a factory.

2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Shanghai City, China, near Hongqiao airport. You can fly to Hongqiao airport or Pudong  airport directly. All our clients, from home or abroad, are warmly welcome to visit us!

3.Q:How can I get some samples?
A: We are honored to offer you samples.

4.Q:How does your factory do regarding quality control?
A: "Quality is priority. ZOTO WIRE people always attach great importance to quality controlling from the very beginning to the very end.  Our factory has gained BV, Intertek, SGS authentication.

 5.Q:Whats your mainly products?

Our mainly products are

Rectangular Enameled wire/ Round Enameled wire/

Ultra Fine Rectangular Enameled wire/NOMEX paper wrapped wire/

Kraft paper wrapped wire/ Polyester film or Kapton covered wire/

Fiber glass wrapped enameled wire/ Electrical rectangular wire/

Macromolecule enameled wire, etc.
