Absorb Dome Light Source AC 180-260V
- zhongshan shenzhen guangzhou
 - T/T Credit Card PayPal

You May Like
-


3030 SMD LED Chips High Lumen PCB Module for Street Light
 -


High Quality Epistar Chip Led Energy Saver PCB Module
 -


LED Chips Led PCB for Down Light With Brightness Color
 -


10 Elelctronic 5730 Smd Led Pcb Board 5W Super Brightness
 -


9W 5730 Smd Led Clock Aluminum Driver Circuit Board
 -


Ac Led 5730 Module Pcb High Quality Super Bright

Product Details
| Place of Origin | Guangdong, China | Brand Name | YUMING | |
| Model Number | YM-XD | Type | Other, LED, Absorb dome light source | |
| Package Type | Surface Mount | Max. Forward Voltage | 265 | |
| Max. Reverse Voltage | 5.0V | Max. Forward Current | 350mA | |
| Max. Reverse Current | 5uA |
Product Description
Product Description
| Product Type | Power(W) | Lumen | Dimension | CCT | Voltage(V) | LED used | Application |
| YM-XD12W | 12W | 1200lm | 128mm | WW/NW/CW or Dimmable triple  | AC 85-265V | 5730 * 24PCS | Indoors |
| YM-XD18W | 18W | 1800lm | 180mm | 5730 * 36pcs | |||
| YM-XD24W | 24W | 2400lm | 180mm | 5730 * 48pcs | |||
| YM-XD32W | 32W | 3200lm | 230mm | 5730 * 64pcs | |||
| YM-XD40W | 40W | 4000lm | 252mm | 5730 * 80pcs |
product advantage:
1.low comsumption: save power up tp 50%
2.high CRI:equivalent to 80% of daylight
3.lifespan over 20000 hours
4.light decay within 10% after 5000 hours
5.more convenient, easily install and retrofit
6.safer,EN62471 & LM-80 certified
attentions:
1. must turn off power before installing
2. Ambient application temperature:-20-45℃
3. No using in humiditive enviroment or without cover
4. Do not install it near flammable or explosive subject
Product application:
indoor lighting:down light, spot ligh, track light,cabin light

Precaution For Use
1 Storage
a) Do not open moisture proof bag before the products are ready to use.and kept at ≤30℃,≤90%RH
b) After opening the package, LEDs should be stored at ≤30℃,≤60%RH
and be soldered within 24 hours. It is recommended that the product be operated at the workshop condition of 30℃ or less and 60%RH or less.
c) If moisture absorbent material has fade away or LEDs expired storage time, baking treatment should be performed on the following condition: 80℃ for 24 hours.
2 Static Electricity
1) LEDs are ESD and surge high sensitive device. Damaged led will show abnormal electrical performance
2) All devices, equipment and machinery must be properly grounded. Wrist band or anti-electrostatic gloves, anti-electrostatic containers are recommended
Handling
1) Handle the component along the side surface by using forceps or appropriate tools.
2) Do not directly touch or handle the silicone lens surface. It may damage the internal circuitry.
3) Do not stack together assembled PCBs containing the internal circuitry.
Logistics & Package
One module in one box, then
12W: 100 boxes in one carton, carton size 64×34×27mm;
18W & 24W: 80 boxes in one carton, 63×39×39.5mm;
32W & 40W: 22 boxes in one carton, 64×34×27mm.
Please refer to below illustration.

FAQ
Q: Are you manufacturer or dealer?
A:We are manufacturer of LED located in Zhongshan , welcome to visit our factory.
Q:Do you have LM-80 report
A:Yes,please contact our sales representative to get soft copy
Q:Can you offer free sample for testing?
A:Yes,free sample is available upon request, but customer will need to pay express charge or provide consignee account
Q:How long is your lead time
A: Normal parts including SMD and COB are 5working days upon payment, for customize parts, will discuss with customer
Q:What’s your MOQ requirement
A: SMD : 100k COB: 10K
