Mini Digital UT Detector

Specifications

Mini Digital UT Detector

Ultrasonic Testing

1. Appearance of new stylish, compact and sturdy, compact and lightweight;
2. Big screen, high-brightness 4-inch color TFT-LCD to solve the deficiencies of the traditional screen display;
3. Independent testing frequency: 2;
4. Frequency Range: 10 Hz ~ 10 MHz, the excellent frequency regulation performance;
5. Gain: 0 dB to 99 dB, a wide gain adjustment;
6 Phase: 0 ~ 359 °, the flexible phase rotation;
7 Intelligent mixer unit number: 1;
8 Lift-off height of :1 - 3mm, no need to cover up the surface layer processing;
9 Fast digital electronic balance;
10.Phase / amplitude, box and fan box, the alarm mode to meet your testing needs;
11. Probe drive: 1 to 8, to meet the different structure of the probe, the true sense of the multi-functional;

12. Independent X and Y gain adjustment
13. Digital filtering: high-pass frequency (0Hz to 2000Hz), low-pass frequency (0Hz to 2000Hz)
14. USB 2.0 (Host) to connect the output capacity
15. Eddy current testing signal playback, analysis, archiving, and printing capabilities
16. Operating System: Linux 2.6

17. Center coordinates: X, Y, adjustable
18. Manipulation Language: Chinese, English

19. Automatically display the calendar, time, battery capacity
20. Easy to operate, real-time screen prompts

21. Charging power supply: 110V ~ 220V
22.Online hotkey graphics, text help.

23.Ambient temperature: -20 ° ~ 60 ° C
24.Built-in rechargeable lithium battery 8000MAH

25. Instrument Size: 120 MM x 80 the MM x 50 the MM
26.Coordinate system: Cartesian coordinates, polar coordinates

27. Weight: 0.6KG

The conductivity measurement of the technical indicators:
1. Measurement methods: the eddy current method
2. Conductivity measurement range: 0.5% IACS-110.0% IACS (0.28-64.0Ms / m)
3. Display Units:% of IACS, and MS / M can be changed
4. Resolution: 0.1% of IACS

5. Lift-off effect: probe compensated to 0.004 "(100um)
6. Precision: ± 1% of IACS
7. Temperature Compensation: probe built-in sensor, with automatic compensation function;
8. Data memory: more than 1000 measurement data can be stored
9. Language: Chinese, English
10. Conductivity measurement results are automatically corrected to 20 ° C value.


Thickness measuring technical indicators:
1. Methods of measurement: the eddy current method

2. Matrix: iron, non-ferrous

3. Conductivity measurement range of 0-1500μm (0-59.04mil)
4. Display unit: um, and mil convertible
5. Resolution: 1um
6. Accuracy: ± 1um
7. Data memory: more than 1000 measurement data can be stored
8. Language: Chinese, English
