Home > Products > Teflon > Low Friction Coefficient Teflon Ptfe Sheet 3mm - 50mm With Good Chemical Resistance
Low Friction Coefficient Teflon Ptfe Sheet 3mm - 50mm With Good Chemical Resistance
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Virgin Recycled Teflon Ptfe Sheet Skived With No Distortion & Low Friction
-
Teflon Ptfe Sheet 3mm Virgin PTFE For Wrapping The Cables Under High Voltage
-
3mm Teflon Ptfe Sheet Good Mechanical Property Ptfe Sheet
-
12mm White Molded Teflon Ptfe Sheet High Low Termparature Resistance Ptfe Board
-
Low Co Eficient Friction Teflon Ptfe Sheet Molded Natural Colorful Sheet
-
Glass Fiber Filled Teflon Ptfe Sheet Low Temperature Resistance Ptfe Plate
Product Details
| Place of Origin | Guangdong, China | Brand Name | FXH | |
| Model Number | PTFE |
Product Description
Low Friction Coefficient Teflon Ptfe Sheet 3mm - 50mm With Good Chemical Resistance
Specifications:
1, diameter:15-200mm
2, length:1 meter
3, ROHS SGS certificate.
4, High gloss and hard surface.
5. Providing services in die cutting holing, punching, slitting as customer's request.
Product description:
PTFE molded sheet is manufactured by molding method with PTFE granular resin. PTFE possesses the best chemical resistance of all known plastics. It does not age. It has the lowest coefficient of friction of all known solid materials and a wide range of practicable temperature from below zero 180° C~up zero 260° C
Product Features:
1) Stretch strength: 15 Mpa
2) Break elongation rate: 150%
3) Pure material guarantee.
4) Corrosion resistant
5) Standard size stocks are available
6) High chemical properties: Wide working temperature range from below zero 180° C~up zero260° C
Product Application:
It is widely applied for aviation,marine,petroleum,petrochemical,metallurgy,electricity,papermaking,environmental engineering,pharmaceutical,foods,machinery manufacturing industries. It is an ideal sealing material for different kinds of flanges and containers.
Property Data:
Property | Unit | Value |
Density | Gms/cc | 2.13- 2.30 |
Tensilestrength | Kg/cm2 | ≥200 |
Elongation | % | ≥250 |
Impactstrength | Kg.cm/cm2 | ≥13 |
Compressivestrengthat1%def. | Kg/cm2 | ≥40 |
Coefficientofthermalconductivity | Deg C | 1.23×10-4 |
Volumeresistivity | Ohmcm | ≥1018 |
Surfaceresistivity | Ohm | ≥1017 |
Safe Operating temperatures | Deg C | - 50 to 250 (biological,pharma,foodapplications) - 50 to 280 (Non-bio/food/pharma applications) |
Dielectricstrength | KV/mm | ≥60 |
Moisture /solvent absorption | - | Negligible |
Combustibility | - | Non-combustible |
Weatherresistance | - | Excellent |
Chemicalresistance | Excellent,except for highly fluorinatingagents |
