Cattle Fence Panel horse sheep stockyard corral panel yard

Product Introduction

Cattle yard panel is usually called cattle panel, horse panel,livestock panel,corral panel etc.It is fabricated with welded hot dip galvanized pipes for the use of fencing livestocks, such as cattle,cow,bull,calves,Dairy sheep,goat,dog.

Features of cattle panel

Panel size: 1.8m highx2.1m wide, 1.6m highx2.09m wide
Horizontal rails: 1.8m high with 6 rails,1.6m high with 5 rails
Fence poat: 40x40mm RHS,50x50mm RHS
Rails: 30x60mm,40x80mm or 40x40mm RHS,50x50mmRHS
Wall thickness: 1.6mm
Zinc coating: 80-100g/m2
Accessories: with caps,lugs,pins and feet

Application of cattle panel (cattle yard panel,livestock panel,corral panel)

the metal animal farm fence panels are widely used in animal husbandry to raising livestocks (cattle/cow/dairy/horse/sheep/goats etc). The connection is very flexible, every panel has lugs so you can  connect the panels according to

your need.
The galvanized metal rail panels are very suitable for animal stall, feedlot fence, horse corral fence, area fence etc.

Heavy duty Cattle Yard Swing Gates.

1. Height 2200mmx Length 2000mm
2.Frame: Vertical pipe: 50mmx50mm RHS with fully

welded caps
3. Cattle Gate Horizontal rail: 80mmx40mmx6 Oval

anti-bruise rails "Bull bars"
4. Finish: HDG 15-micrpns
5. Fully weded oval pipes, post & brackets
6. Supplied with two HDG Pins

Cattle Loading Ramp

1. Cattle ramp: 3.2m length.
2. Overall height 3,242 mm. Inner width: 735mm
3. Adjustable ramp height: from 585mm-1500mm.
4. Winch Mechanism with 10mm wire rope HDG.
Eliminates manual lifting
5. Frame: 50mmx50mmx2.00mm
6. Side panels: 6x50x50x2.00mm ( side gal sheeting
1.5mm thick)
7. Floor: HDG 3mm checker plate with steel struts for
better grip
8. Pre-galvanized, HDG after fabrication or as client
requst

Heavy duty Sliding Gates

1. Height 2200mmx inner width 800mm
2. Frame: Horizontal & Vertical pipe: 50mmx50mm RHS with fully welded fully welded caps
3. Horizontal rail: 40mmx80mmx6 Oval anti-bruise rails "Bull bars"
4. Nylon rollers
5. Finish: HDG 15-mica ns

Transportation

The shipping company for more than 10 years to protect the security of goods and quickly reach.

To keep products safe,we will take photos when loading and track the products situation for long transportation to make sure the product arrive at the designation ASAP.
