2016 Hot selling 1220x3000mm Aluminium Composite Panels with high quality

FOB Price

US$ 5 - 18 / Piece

1000 Pieces(Min. Order)

Port QINGDAO
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	SUNSHINE
Model Number	1220*2440mm	Usage	Outdoor
Function	Anti-Static, Antibacterial, Fireproof, Mould-Proof	Surface Treatment	Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, PVDF Coated

Product Description

Aluminum Composite Panel is a composite material made of aluminum and non-combustible mineral filled core. Though the core material does contain a small amount of combustible polyethylene, the main ingredient of the non-combustible mineral filled core does not permit the proliferation of flame and restricts smoke. It is a fire-safe material that passes mandatory requirements for exterior and interior application.It is an ideal material for external claddings, roof of pedestrian passage and other architectural applications.

Aluminium Composite Panel (ACP) or Aluminium Composite Material (ACM) is a widely-used term describing flat panels that consist of a non-aluminium core bonded between two aluminium sheets. Aluminium sheets can be coated with PVDF or Polyester paint. ACPs are frequently used for external cladding of buildings (building facades), for insulation and for signage.

Detailed Images

Materials:

1) Front side: aluminum roll coated with PVDF orPE
2) Core: plastic/ fireproof materials
3) Rear side: aluminum or aluminum coated with polyester

Specification

Aluminum alloy : AA1100, AA3003

Aluminum skin thickness: 0.04mm /0.06mm /0.08mm/0.12mm/0.15mm/0.18mm/ 0.21mm/0.30mm 0.35mm / 0.40mm / 0.45mm / 0.50mm

Surface coating : POLYESTER, PVDF, EMBOSSED POLYESTER
Middle core: recycle PE / fireproof core B1/A2

Panel thickness: 2-6mm

Width:1000mm, 1220mm, 1250mm, 1500mm,1600mm,2000mm
Length: 2440mm till 6000mm

Color: Matt, Glossy, Metalic series, Factory standard, RAL color chart

Special size and colors can be customized.

Characteristics:

1) Excellent fireproof property
2) Super peeling strength
3) Perfect cold resistance performance
4) Excellent surface flatness and smoothness
5) Superior weather, corrosion, pollutant resistance
6) Even coating, various colors
7) Superior impact resistance
8) Lightweight and easy to process
9) Easy to maintain

Application:

1) Gas piping, cables, building materials, etc (this product fills a gap in the domestic construction materials field, with performance indexes superior to panels manufactured overseas)
2) Curtain wall decoration for buildings where security is important, such as airports, hospitals and research centers
3) Curtain wallboards for outside walls of normal buildings
4) Renovations of old buildings and movable houses
5) Reformation and decoration for indoor walls, ceilings, bathrooms, kitchens and balconies
6) Facades
7) Billboards, exhibition desks and notice boards
8) Wallboards and ceilings for tunnels
9) Materials for industrial application, car and ship bodies
