PVC BABY HAND PUMP

        Wall Mounted Hand Pump is made from Cast Iron & Stainless steel for long lasting life. It is wall mounted therefore can be used easily to suck water from underground storage tank and water supply from ground level to upstairs. It has washer size of 76.2 mm hence can sucks & supply water easily compare t other hand pumps.

It is Ideal for sucking water from 20 to 25 feet below ground level and can easily supply waters 20 feet above ground level. Best Suitable for domestic water supply up to second floor without electricity.

PRODUCT SPECIFICATINS:-

Height without Handle                :- 13 ” (13 inches)

Height with Handle                     :- 18”  (18 inches)

Weight                                        :- 3.9 Kgs. Approx

Material Used                             :- Stainless steel /Cast Iron

Cup Seal (Bracket washer size) :- 3 ”  (3 inches)

 Suction Capacity                        :- 20 to 25 feets

 Pipe fitting size                          :- ½  ” (12.10 mm)

 Color / Paint                               :- Dark Green or Blue standard Paints

 Packing                                      :- Corrugated Box Packing

Maximum Discharge Water      :- 750 Liters per hour on per second / stroke basis

        This PVC Baby Hand pumps is made from HDPE PVC pipes & Cast Iron,hence very light weight.It is having washer size of 76.2 mm.Easily sucks water from 20 to 25 feet below ground level.It can be easily fitted on underground water tank of any house and can easily sucks water from them.It is best suited for domestic usage with zero electricity consumption.

        Creative Engineers wall Mounted  hand pump is Equipped  with flat washer with weight for water storage in body. This hand pump is also equipped with piston rode with Inner Flower, Head Flange , Base Flange , Handle , Doubly & “U”.

PRODUCT SPECIFICATINS:-

Height without Handle                :- 15 ” (15 inches)

Height with Handle                     :- 19 ½”  (19.5 inches)

Weight                                        :- 3.7 Kgs. Approx

Material Used                             :- Cast Iron/ PVC

Cup Seal (Bracket washer size) :- 3 ”  (3 inches)

 Suction Capacity                        :- 20 to 25 feets

 Pipe fitting size                          :- 1 ” (25.04 mm)

 Color / Paint                               :- Dark Green or Blue standard Paints

 Packing                                      :- Corrugated Box Packing

Maximum Discharge Water      :- 1500 Liters per hour on per second / stroke basis
