Home > Products > Rotary kiln & dryer > High Efficiency Straight Tube Rotary Kiln With ISO and CE Inspection

High Efficiency Straight Tube Rotary Kiln With ISO and CE Inspection

FOB Price

USD $1,000 - $99,999 / Set

1 Set(Min.Order)

Port Shanghai Tianjin Qingdao
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China	Brand Name	Zhongke
Model Number	YZ3060	Condition	New
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

High Efficiency Straight Tube Rotary Kiln With ISO and CE Inspection

Product Description

Introduction:

Rotary kiln is refer to rotate calcinations kiln ,belongs to contruction material equipment. Rotary kiln can be divided into cement kiln ,metallurgy chemical kiln and lime kiln according to different materials. Cement kiln is used for making of cement clinker and there are dry and wet methods to make cement. Metallurgy chemical kiln is used in metallurgy industry and ironworks for lean iron ore,chromium ore and ferronickel ore calcinations, which is used for calcining of high aluminum vandal ochre in refractory material industry :for calcining of calotte and aluminum hydroxide in aluminum manufacturer: for calcining of chrome sand ore and chrome powder ore in chemical plant ,lime kiln are used for calcine dolomite and active lime which is used in steel plant and ferroalloy factory

Working Principle:

Rotary cylinder dryer mainly consists of axially symmetrical, Yang stripper plate, gearing, supporting device and seals and other parts. Dryer is one with horizontal direction slightly sloping cylinder, material into from high end to join, high temperature hot flue gas and material flow into the cylinder, along with the cylinder body rotation, material operation to lower end. On the wall of the cylinder copy board the material start to copy and asperse, make the material of surface in contact with air drying rate increases, in order to improve and promote materials on. After drying product from the bottom bottom collection.

Advantages

The rotary kiln has advantages of reasonable structure, high efficiency, low energy consumption and convenient for transportation, and convenient and reliable operation; Therefore, the consumption of the coal and the electricity is lower than the common ones. While the production capacity is higher than 10-15%.

Technical parameters:

Type	Modal	Barrel diameter (mm)	Barrel length (mm)	Slope (percentage)	Capacity (t/h)	Speed (rpm)	Motor power(kw)	Weight (t)
Straight tube rotary kiln	YZ1225	1200	25000	4	3	0.53-5.25	22	34
	YZ1632	1600	32000	4	3.5	0.53-5.25	15	46.82
	YZ1828	1800	28000	4	4	0.28-2.84	30	59.39
	YZ1845	1800	45000	4	4.5	0.26-2.61	30	80
	YZ1636	1600	36000	4	1.2-1.9	0.26-2.61	22	51.023
	YZ1939	1900	39000	4	1.6-3.4	0.31-2.82	37	70.704
	YZ2044	2000	44000	3.5	2.4-4	0.22-2.26	37	97.135
	YZ2245	2200	45000	3.5	3.2-5.3	0.23-2.25	45	125.462
	YZ2550	2500	5000	3.5	6.2-7.4	0.68-1.45	55	179.606
	YZ2555	2500	55000	3	7.3-9.8	0.79-2.38	55	191.203
	YZ2820	2800	20000	4	15-18	0.8-1.45	75	186.373
	YZ3028	3000	28000	4	18-23	0.8-1.45	75	180.737
	YZ3060	3000	60000	3.5	16-20	0.49-2.41	90	272.510
	YZ3226	3200	26000	4	22-27	0.8-1.45	90	185.107
	YZ 3255	3200	55000	3.5	17-23	0.1-1.52	75	271.673
	YZ3529	3500	29000	4	28-40	0.16-1.38	110	238.031
	YZ3560	3500	60000	3.5	28-40	0.65-2.25	125	347.872
	YZ4030	4000	30000	4	52-70	0.38-3.52	160	415.103
	YZ4060	4000	60000	3.5	55-78	0.38-3.52	315	514.223
	YZ4262	4200	62000	3.5	80-105	0.38-3.52	315	541.615
	YZ 4565	4500	65000	3.5	110-140	0.38-3.52	420	609.526
	YZ4772	4700	72000	3.5	150-190	0.38-3.52	550	795.325
Reducing rotary kiln	YB1626	1600/1400	26000	4	0.7-1.1	0.41-3.85	18.5	38.621
	YB1939	1900/1600	39000	4	2.2-2.7	0.27-2.58	22	60.841
	YB2245	2200/2000	45000	3.5	2.5-3.5	0.25-2.28	30	88632
	YB2545	2500/2200	45000	3.5	4.5-6.2	0.25-2.18	45	102.367
	YB2845	2800/2500	45000	3.5	7.5-10	0.68-1.45	55	192.622
	YB3560	3500/3000	6000	3.5	23-32	0.65-2.28	125	310.263
