Reclamation Plant for Used Mixed Oil

Specifications

Application:

The plant is suitable to regenerate used internal-combustion engine oil including diesel engine oil, gasoline engine oil, and used hydraulic oil, other used machinery’s lubrication oil.

It can effectively remove colloid, oxid, acid, pitch, particles, impurities, water, gas in the used oil. Specially, it can restore the color of used oil and remove the scent rapidly.

Edges of GER:

1     Two main filtering systems in the plant which can ensure the plant works continuously by batch. Special designs make plant small size, light weight and low noise.

2     The filters in filtering systems are made of stainless steel. It can extend lifetime of filtering systems and make it unnecessary to be replaced regularly like tradition fabric or paper filters.

3     Heat preservation material can keep heating quite efficient.

4     Automatic reverse-washing system will extend the life time of filters and improve the performance of the filters. All above methods make the plant low maintenance and replacement expenses.

5     No acid used during operation. Exhaust gas removing system can remove exhaust gas quickly and efficiently. Both of them make operation more environmentally friendly.

6     High performance security system including pressure protection device and automatic temperature controller makes operation safely.

7     Can redesign according to different customers’ needs. We are able to provide service of Turn Key Project.

Technical Specifications:

Model type:  GER-1

Treatment Capacity:  2000L/8H

Regeneration rate:  70-90%

Working pressure:  -0.095-0.4MPa

Temperature:  60-200 degrees Celsius

Working noise:  less than 90 dB(A)

Heating power:  96 KW

Inlet / outlet Pipe Diameter: D42 Mm

Weight:  6000 Kgs

We also provide plants of different capacities: from 4000 to 10000L per 8 hours. If you have further need please feel free contact us.
