Product Description
Specifications
1. Pen-style visual fault locator with replaceable ferrule2. Multi output power available
3. 2.5mm universal connector
VFL6502 series pen-style visual vault locator is the best selling model.
It adopts the aluminum alloy case, which could be painted to different colors. The aluminum alloy material makes touching more confortable and smooth.
VFL6502 series pen-style visual vault locator provides a stable visible red light for users to easily locate fiber faults, broken or micro-bend in installation or maintenance of optical network. With the modulation function, it is also applicable for end to end fiber identification.
Features
- Pen-type visual fault locator
- Aluminum alloy body and light weight
- Removable ferrule
- Multi output power available
- 2.5 mm universal connector
- Constant and stable output power
- CW or 2Hz modulated signal
- Low battery warning
- Up to 60 hours battery life
Specification
Model | VFL6502 |
Central Wavelength (nm) | 650±10 |
Emitter | FP-LD |
Output Power (mw) | 1/3/5/10…. |
Optical Connector | 2.5mm universal
|
Modulation (Hz) | 2~3 |
Battery | AA (2pcs) |
Operating Time (h) | >65@650nm&1mw
|
Operating Temperature (°C) | -10~+45 |
Storage Temperature (°C) | -40~+70 |
Dimension (mm) | 15*180 |
Weight (g) | 120 (excluding battery) |
Standard Accessories
1) Main Unit
2) Battery
3) Cleaning Stick
4) Carrying Bag
Ordering Information
VFL6502-OP
1) OP=Output Power
OP1: 1mw
OP2: 3mw
OP3: 5mw
OP4: 10mw
OP5: 15mw
OP6: 20mw
OP7: 30mw
OP8: 45mw
OP9: 60mw
