4*25mm2- 4 AL Core XLPE Insulated PVC Sheathed Steel-tape Armoured Power Cable -YJLV22

Specifications

1. Professional manufacturer

2. Reliable quality

3. The most competitive price
3. Fast delivery
4.BV, CCC, CQC,BV

   4*25mm2-NEW Chinese cable supplier low voltage Aluminum 4 Core XLPE Insulated PVC Sheathed steel tape armoured Power Cable-YJLV22

Product Description

Application

These cables are suitable for indoor, channels, conduits and unable to bear mechanical stress.

Properties of PVC Power Cable

1. The long-time permissible working temperature of cable conductive core is no more than 70°C.

2. During short circuit (max permanent time is not more than 5 seconds), the max temperature of cable conductor is not more than 165°C.
3. The difference level of laying cable is not restricted. When laying the cable, ambient temperature is not lower than 0°C.
4. They have good chemical stability, and properties of acid, alkali, salt, oil, solvent and flame resistance.

Properties of XLPE Power Cable

1. The highest allowed operating temperature of conductor for long-term working is 90°C.

2. In short circuit (Max long term is no more than 5 seconds). The highest temperature for conductor is no more than 250 °C.

3. The environment temperature should not be lower than 0°C when laying.

4. Excellent electrical performance, resistance to chemical corrosion.

5. Can stand advisable traction when laid. Can stand traction from Outside.

Technical parameters

Attention: We can provide more information than above data, if needed.

 The above are just some examples.

Inquiry &order advice

Due to the wide range of cables in the catalog, we advise; when you inquire or place an order, please provide as much information as possible. Please use the following table as a guide:

Our factory

Product display

Flow pictures

Packing

Inspection

Certification

Our company

Since its foundation, Chengdu Licheng Cable Co., Ltd has always been adhering to this philosophy: “Quality first; Customers oriented; Credible cooperation; Mutual benefits.” Our company has successfully passed ISO9001:2008 quality management system certification and has been awarded “The enterprise with a stable product quality in Sichuan Province”, “The member of quality and technology supervision network in Sichuan Province ”, “Chinese famous brand ”,and “Sichuan famous brand”, etc. We promise to supply satisfactory pre-sale, in-sale, and after-sale service for our clients and try our best to meet their demands.

Exhibition

Product quality and service commitments

1. OEM &ODM service are available based on official & legal authorization.

2. Strict quality control system.

3. The fastest speed of delivery

4. Excellent quality with the most competitive price.

5. Strong technical support

6. Free sample is available with economic express fee.

7.Prompt shipment, cargoes loading photos sent to you by e—mail

8. If one meter is less, you will get ten meters for compensation.

We cancustomizethe products according to your requirements

Please don't hesitate to contact us if you have any problem. Your inquiry is welcomed at anytime.

We are confident in rendering our best service to you with promptness & efficiency.
