Home > Products > Electric City Bikes > Buy Green Female City Electric Bike Electric Dirt Bikes for Adults With CE, EN15194

Buy Green Female City Electric Bike Electric Dirt Bikes for Adults With CE, EN15194

FOB Price

Negotiable / Piece

20 Pieces(Min. Order)

Port shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Wattage	200 - 250w	Voltage	36V
Power Supply	Lithium Battery	Wheel Size	Other, 26“
Motor	Brushless	Certification	CE
Frame Material	Aluminum Alloy	Foldable	No
Max Speed	Other, 25KM/H	Range per Power	31 - 60 km
Place of Origin	Jiangsu, China	Brand Name	Merry Gold
Model Number	TDB01Z

Product Description

TDB01Z e bike,electric bicycle

Electric system		Main components
Motor	light weight high speed brushless.	Frame	6061 al alloy.
	geared hub motor.	Tyres	26"*1.75/2.0 KENDA brand.
	180W-250W for European.	Rim	Al alloy double wall and CNC side wall.
	250W-500W for USA & Canada.	Front fork	Al alloy suspension.
	200W for Australia & New Zealand.	Front brake	V brake ( Disk brake available).
Battery	36V/10Ah, 36V/13Ah ploymer li-ion.	Rear brake	servo brake ( Disk brake available).
	All battery with electric protection circuit.	Speed gears	SHIMANO 6/7 speed gears.
PAS	1:1 intelligent pedal assistant system.	Derailleur	SHIMANO TOURNEY
Controller	36V intelligent brushless	Handle bar	ZOOM Al alloy.
Charger	AC 100V-240V, 2 Amps smart charger.	Stem	ZOOM Al alloy.
	Charge time:4-6 hours.	Brake lever	Al alloy, cut-off when braking.
Throttle	Twist intelligent speed control.	Chain	Rust resistant chain.
Performance		Chain wheel	Steel 38T, al alloy crank.
Max speed	25km/h(EU),32km/h(USA & Canada).	Mudguard	steel.
Range	50km with full electric (36V/10Ah battery).	Rear rack	Al alloy.
	80km-100km with PAS.	Saddle	Soft comfortable.
Max load	100kg.	Seat post	Steel folding or aluminium suspension.
Net weight	23.6kg including battery.	Pedal	City style pedal with reflector.
Gross weight	28.0kg including package.	Optional parts	Front / rear light, tool kit, rack bag helmet.
Capacity	80pcs/20ft container, 206pcs/40 HQ.		Lock, water bottle,basket ,speed meter.

lifepo4 electric bike conversion kit

Packaging & Shipping

Our Services

1. Sample is possible, but we need to add extra fee;

2:1% Free spare parts

3: Battery Waranty 18 months

4:LOGO design free for full cotainer;

Company Information

FAQ

+ How fast do MG Electric bike go ?

For our 250W e-bikes and electric bike conversion kits, 25km/hr (EN15194 Standard, applicable in all states and territories). Our off road kits are capable of much higher speeds.

+ How far can you go once full charge ?

The range depends on which MG product you’re on, riding style and terrain. If you are going up hills often, you will get less distance. The ranges vary from 30km up to 80km. The more you pedal to assist the e-bike, the further it will go.

+ Do MG e-bikes make noise ?

No. They are not loud at all. Compared to automobiles or motorcycle engines, an electric bike is virtually silent.

+ Will my MG electric bike go up hill ?

Yes, especially with motor-assist. It will give you more power just when you need it.

+ Do electric bikes charge when you pedal them ?

No, this is not the purpose of having an electric bicycle. The purpose is not to have to pedal harder to charge the bike battery. Instead, the aim is to pedal less and make it easier for you to get around.

Electric bikes don’t have this feature because the effort that the rider puts in to pedaling can only go so far. Either the effort from pedaling is used to assist the bikes motion, or it could charge the battery. Unfortunately there’s no such thing as ‘free energy’ so you could image pedaling an e-bike that is also trying to charge the battery would make it very hard to pedal, as you’d be battling against the resistance of an added generator (not to mention the weight and cost) and also trying to assist the bikes motion. The most efficient use of the rider’s effort is to assist the motor in moving the bike, extended the range.

+ Can the battery be removed on the e bikes ?

Yes the batteries are all locked and the key unlocked the battery for easy removal in 10 seconds.

+ Does MG e bike need servicing ?

There is no more servicing than a standard pedal bike. All of the electrics are sealed so no maintenance is required over and above a standard bike.

More information you want to know, welcome to contact with us by mail or call directly.

...
