S1303MD metal gear 270degree 13kg digital robot servo

S1303MD metal gear 270degree 13kg digital robot servo

Features:

High presicion copper gears made by CNC;

Select torque motor,could compare with import one;

1million life Potentiometer;

expert and experienced in circuit for 8 years;

TOP choice on case plastic,and best mold manufacture

Futaba,JR,SANWA,Hitec compatible.

Waterproof,12bit Digital IC

Specifications Figure:

Specifications:

                    Item No. S1303MD

Operating Voltage:     4.8V~7.4V

Speed:                           0.16 sec/60deg (4.8v)    0.14sec/60deg (6v)

Torque:                         13.5kg.cm (4.8v)          14.8kg.cm (6v)

Size:                               40mmX20mmX38.5mm

Weight:                          56gram

Motor:                            3 pole Core motor

Gear Train:                   Metal(copper gear)

Ball Bearing:                2BB

Dead band width:       2usc

Interface:                       (JR)

Wire length:                  30cm

Type:                              Digital,2BB,metal gear

Rotation angle:            270degree(PWM500-2500us)

Product View:

Important Notes:

*Please specify the plug(JR or Futaba connector),or we offer JR plug for you,for it is compatible.Futaba plug.
*Please do read the instruction before you install the servo.Rubber grommet must be used to reduce vibration when you install the servo on GP airplane,GP car or GP boat.
*Please choose suitable servo for you rc model.Torque overload will damage your servo.
*Keep the servo clean and away from dust,corrosive gas and humid air.
*Specification are subject to change without notice

Packing include:

     1pcs x S1303MD  servo

     Accessaries:servo horns,rubber grommets, eyelets and mounting screws

         1 x double sided servo horn       1 x 4-arm servo horn    1 x 6-arm servo horn    1 x round servo disc
         4 x rubber grommets with brass inserts           4 x mounting screws
         1 x mounting bolt 3x 8mm for servo horn installation on the ball raced brass output shaft with 25T-spline drive
     GW: 75 g

Packing:

Certificate:
