Home > Products > Back-end packing equipment > Carbonated Drink Bottle Warming Machine
Carbonated Drink Bottle Warming Machine
- shanghai port for Carbonated Drink Bottle Warming Machine
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | JINRI | Model Number | WP-PLJ | |
| Processing Types | Carbonated Beverage | Voltage | 380VAC | |
| Power(W) | 2-18kw | Weight | 5000kg | |
| Dimension(L*W*H) | 8000*200*650 | Certification | CE ISO | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Carbonated Drink Bottle Warming Machine
This machine is usually used after carbonated beverage finished cold filling and sealing, when enter the spray tunnel, the water with the function of high-pressure pump, uniformly spray on the bottle body. The bottles move slowly in the chain, when they are out the tunnel, they can reach the normal temperature, then achieve the purpose of warming. This machine can also be used for secondary sterilization for fruit juice and beer.
Main Technical parameters | |||
Model | WP-PLJ-4000 | WP-PLJ-6000 | WP-PLJ-10000 |
Capacity(b/h) | 2000-4000 | 4000-6000 | 8000-10000 |
Bottle inlet temp. | 3-5 | ||
Bottle outlet temp. | <45 | ||
Steam pressure | 0.5-0.6MPa saturated steam | ||
Width of belt(m) | 1.22 | 1.5 | 2 |
Circling water(m3/h) | 6.3 | 10 | 20 |
Water consumption(m3/h) | 1 | 1.5 | 2 |
Water pressure:>=0.2Mpa,water temp. is 20°C | |||
kg/h steam consumption | 200 | 350 | 600 |
Overall dimension(mm) | 8000×1500×1650 | 8000×1800×1650 | 8000×2200×1650 |
Total weight(kg) | 3200 | 5000 | 6200 |
pictures for Carbonated Drink Bottle Warming Machine
If you are interested in our product, you can contact me as below:
Contact Us
- Zhangjiagang Jinri Beverage Machinery Co., Ltd.
- Contact namebella jiang Chat Now
- Phone0086-512-56762853
- AddressYongli Industry Leyu Town Zhangjiagang City , Suzhou, Jiangsu
