Description for 5 gallon drink water bottling plant

1. QGF series barrel production line is specially used for 5 Gallon&4 gallon&3 gallon drinking water. This machine integrates washing, filling, capping into one unit.

2. This machine integrates Sterilizer, Washing, Filling, Capping into one unit. It is the good ideal for produce the mineral water, distilled water, pure water equipments.

3. The full ling incude automatic decapper, internal and external barrel scrubber, cap elevator and heat shrinker

4. The machine is compactly conformed to small occupation of land and high efficiency and reliable and stable quality and high automaiton. Only two operators are neededfor a line, which is wholly automatic barreled equipment with motor, electric unit and air three in one.

technical parameter for 5 gallon drink water bottling plant :

Pictures for  5 gallon drink water bottling plant

300BPH 5 Gallon water bottling plant

Brushing machine

automatic decapper machine

pail bagging machine

Cap Decapper

This model automatic decapper is special equipment for 5-gallon retrieving barrel.It does not damage caps.

This machine adopts computer control and its capacity can be adjusted.Cap pulling organism from AIRTAC adopt pneumatic adjustment,which solves the problems of tolerance of barrel height and tolerance of barrel's mouth,and increases cap pulling success greatly.304 stainless machine frame and machine body.

Outer Brusher

Function:clean the extemal of 5 gallon bottles with brush and water

1. Rotary style to wash the bottle body.

2. Material of machine frame and body:all 304 Stainless Steel.

3. All 304 stainless steel pipeline,valve and connector,fine polish,no death corner

4. Linear washing style with ø350brush 1pc ø200 brush 3pcs 300*3 brush 20pcs

5. Water pump:with 304 stainless steel pump

6. Washing tank:size 500*300*600*1.2,304 stainless steel

7. No bottles,no washing

Performance advantages:

  Control Interface - knob control,pedal control switch

  Functional improvement - have anti-drip device under the material

  Electrical components - are used internationally renowned brands,ensuring that equipment reliability,high accuracy

   Mechanical components - and access to some materials of high quality non-toxic corrosion 316 stainless steel and PTFE hoses.Other machine parts are of high quality 304 stainless steel.

  Maintenance situations - the machine meet the GMP requirements,easy disassembly,cleaning maintenance

  Exchange standard - filling specifications change,simply adjust,easy to get.

JINRI Company and office

Packing system

Customer's service:

1. JINRI company can provideo turn-key project for you, only you have any idea to start beverage factory              plant.

2. JINRI company have professional design team, our engineer can draw bottle samples and flow chart of

    workshop for you .
3. JINRI company give you the best quotation for all kinds of beverage production, only you can tell me which

    kind of drink you want to product, what is your capacity(how many bottles one hour) what is you bottle

    material, pet or glass,etc

After service:

1. We send the engineers to help installing, commissioning and training, the engineers start from our factory         area.
2. We supply below necessary documents with the machine:
    a. Machine layout
    b. Electricity diagram
    c. Machine certificate
    d. General manual book/maintenance book
3. After one year guarantee, the seller provides payable spare parts and technician’s VISITING maintenance

    service.
