Home > Products > 3-5 gallon filling machine > 5 Gallon Barreled Water Filling Machine (2015New)
5 Gallon Barreled Water Filling Machine (2015New)
- shanghai port for 5 Gallon Barreled Water Filling Machine
- T/T Credit Card
You May Like
Product Details
| Condition | New | Application | Beverage, Food, Other, Beverage, Food, Machinery & Hardware | |
| Packaging Type | Case | Packaging Material | Wood | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380/220VAC | Power | 1.75-8.5kw | |
| Place of Origin | Jiangsu, China | Brand Name | JINRI | |
| Model Number | QGF | Dimension(L*W*H) | 3650*1500*1800mm | |
| Weight | 800-11800kg | Certification | CE ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
5 Gallon Barreled Water Filling Machine (2015New)
Characteristics for 5 Gallon Barreled Water Filling Machine :
The machine is used for 3 gallon & 5 gallon water filling, which is composed of washer, filling and capper.
1.304 stainless steel insert type filling nozzle, two time high precision filling, filling volume adjustable.
2. Water pump: 304 stainless steel pump. three washing pumps and one filling pumps.
3. Mitsubishi PLC controlling system, all full-automatic working, Schneider & Omron brand other electric parts.
4. With AIRTAC brand air cylinder, F.R.L. Combination and Electromagnetism valve for air cylinder.
5.Machine frame and body: all 304 Stainless Steel, combine with clear fiber glass windows.
technical parameters for 5 Gallon Barreled Water Filling Machine :
| Model | Filling Heads | Capacity (B/n) | Volume(L) | Barrel Size(mm) | Gas pressure(mpa) | Gas consumption(m³/min) | Motor power(kw) | Rated voltage(v) | Outline dimension(mm) | Weight(KG) |
| QGF-100 | 1 | 100-120 | 18.9 | φ270×490 | 0.4-0.6 | 0.37 | 1.75 | 380V/50Hz | 3790×650×1550 | 800 |
| QGF-300 | 2 | 200-240 | 18.9 | φ270×490 | 0.4-0.6 | 0.6 | 3.22 | 380V/50Hz | 3550×800×1800 | 2800 |
| QGF-450 | 3 | 300-400 | 18.9 | φ270×490 | 0.6 | 0.6 | 4.8 | 380V/50Hz | 3550×1200×1800 | 4000 |
| QGF-600 | 4 | 600 | 18.9 | φ270×490 | 0.6 | 1.2 | 8.5 | 380V/50Hz | 3650×1500×1800 | 5500 |
| QGF-900 | 8 | 900 | 18.9 | φ270×490 | 0.6 | 2.2 | 8.5 | 380V/50Hz |
| 7500 |
| QGF-1200 | 12 | 1200 | 18.9 | φ270×490 | 0.6 | 3 | 8.5 | 380V/50Hz | 2560×2350×2750 | 9500 |
| QGF-2000 | 16 | 2000 | 18.9 | φ270×490 | 0.6 | 4.5 | 8.5 | 380V/50Hz | 3100×2800×2750 | 11800 |
Advantage:
- The machine integrates rinser, filler and capper together.
- The machine is of stainless steel, resisting corrosion and easy to clean.
- The main electrical components and gas circuit elements are all of international brand.
- Water pump is Nanfang, Hangzhou (Grundfos is available)
- Nozzle is of America’s Spraying System Company’s technology.
Pictures for 5 Gallon Barreled Water Filling Machine :
