EM9-GD3-015 Without Battery 380VAC Output Type 20hp Solar Submersible Pump Inverter
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
EM9-GD3-018 Without Battery 380VAC Output Type 25hp Solar Submersible Pump Inverter
-
EM9-GD3-022 Without Battery 380VAC Output Type 30hp Solar Submersible Pump Inverter
-
220V-240V Single Phase Vector Control ac Variable Speed Drive for Motor Controller 0.4kW-7.5kW 0-600Hz
-
200V-240V Single Phase Vector Variable Speed Converter for ac Motor Controller 3.4kW 50Hz/60Hz
-
200V-240V Single Phase Sensorless Vector Variable Speed Converter for ac Motor Controller 5.5kW 50Hz/60Hz
-
200V-240V Single Phase Sensorless Vector Variable Frequency Driver for ac Motor Controller 7.5kW 50Hz/60Hz
Product Details
| Place of Origin | Guangdong, China | Brand Name | EMHEATER | |
| Model Number | EM9 | Output Power | Other, 0.4-630KW | |
| Output Type | Triple | Size | 236*149*180 | |
| Weight | 3~500kg | Input Voltage | DC310/540V±20% or AC220/380V±15% | |
| Output Voltage | 3phase AC220/380V±15% | Type | DC/AC Inverters | |
| Output Frequency | 0~600hz | Output Current | 2.5~1100A |
Product Description
EM9-GD3-015 without battery 380VAC output type 20hp solar submersible pump inverter
Feature: (approved by CE)
1.Built-in AVR function, can automatic keep output voltage stable.
2. Input Voltage Range:DC310/540V±20% or AC220/380V±15%.
3. Input Frequency Range:DC or 1&3phase AC: 47~63Hz
4. Output Voltage Range:3phase AC220/380V±15%.
5. Output Frequency Range:0~600Hz
6. Overload Capacity:60s with 120% of rated current, 10s with 150% of rated current.
7. Control Mode: Sensorless Vector Control (SVC); Constant Torque; V/F Control.
8. Speed Accuracy: Sensorless Vector Control :±0.5% of maximum speed (SVC)
9. Starting Torque: 150% of rated torque at 0.5Hz (SVC).
10.Programmable Timing Running(Simple PLC)
11. All model are integrated IGBT, and optional displaying 4 lines keypad.
12.The malfunction ratio is 0.1% within 18 months warranty.
1. Soft starter: general 220V~240V, 380V/400V/415V, 480V, 690V 3 phase 7.5kw~630kw
Soft starter Cabinet and explosion-proof soft starter.
1)EM9 series: General used Single phase/3 phase 220V 380V 480V
Special used for Ball mill machine, Injection machine,CNC machine etc.
2)EM11 series: General used Single phase/3 phase 220V 380V 480V
3)Solar Pump inverter: 310/540VDC, 220VAC,380VAC input, 380VAC 3 phase output
4. Accessories: AC filter, sine wave filter, AC/DC choke, braking resistor and unit etc.
