Hydraulic Swing Arm Cutting Press CSC-22T
Negotiable
/ Set
1 Set(Min. Order)
- Shanghai Port China
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | EOMAE | |
| Model Number | CSC-22T | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
* Hydraulic Swing Arm Cutting Press* Durable machine structure
* Easy to operate
* Reasonable price
* CE Certified
CSC-22T Hydraulic Swing Arm Cutting Press
Application
- Suitable for cutting shoe sole, bag, glove, gasket, plastics, rubber, leather, synthetic leather and leather products, fibers, textiles, paper products, as well as other similar products...
- Widely used in plastic & rubber, handbag, paper, and other industries...
Key Features
- Solid cast iron body structure, strong and durable;
- Hydraulic drive mode, all hydraulic system components are of superb quality;
- Automatic oil lubricating system reduces machine's wear and tear;
- Double direction oil way design provides stability and reliability;
- Machine's beam can be rotated flexibly and freely, easy to operate;
- Low maintenance;
- Low noise;
- Two-handed operation design and emergency stop device can ensure safe operation;
- Compact body design helps to reduce waste and save energy;
- Lower limit position is controlled by electronic delay circuit;
- Cutting head height is controlled by the handwheel, cutting stroke is adjusted by the timer, so it's very easy to achieve optimal cutting position;
- Setting is convenient and accurate;
- The inertia of the handwheel is stored to save energy;
- Qualified parts and superb workmanship ensure the working stability and service life.
Options
- Counting function
- Machine color
- Platen size can be customized
Main Technical Data
| Model: | CSC-22T |
| Cutting Force: | 22 Ton |
| Platen Size: | 450 x 550 mm |
| Bed Size: | 500 x 1000 mm |
| Cutting Stroke: | 0-75 mm |
| Distance between Platen to Bed: | 65-150 mm |
| Motor Power: | 1.5 KW |
| Hydraulic Oil: | 60 Liter of 46 anti-wear hydraulic oil |
| Net Weight: | 1000 KGS |
| Dimension: | 1100 x 1100 x 1400 mm |
Machine Photos
