120KW Deutz Diesel Generator Set For Sale
- Fuzhou China
- T/T
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | BAIHUA FMW DD | |
| Model Number | GF | Output Type | AC Three Phase | |
| Speed | 1500/1800R/MIN | Frequency | 50/60HZ | |
| Rated Power | 24KW-120KW | Rated Voltage | 400V/230V | |
| Rated Current | 43.3A-1806A |
Product Description
Deutz Engine Generator Sets
Well-know that Germany is the heaven of engines such as BMW,Audi,Opel and so on,and Deutz with over 140 years history in Germany is one of there members. No matter what the demands. No matter where in the world. You can find that Deutz is under heavy working in each field who is in need of power generation.The name DEUTZ has a firm place in the world of machine manufacturers and machine operators.
Deutz in China is a cooperation between Deutz and Weichai Engine Co.,LTD. Who is the most popular and famous engine factory in China. Deutz engine 226B series is fuel-economical, super-powerful, reliable, rigid engine body, durable and safe.
Rated Output: From 24kw to 120kw
Both Open Type and Silent Type are available.
| TECHNICAL DATA | ||||||||
| Model | GF2-24 | GF2-30 | GF2-40 | GF2-50 | GF2-75 | GF2-100 | GF2-120 | |
| Engine | Model | D226B-3D | TD226B-3D | TD226B-3D | TD226B-4D | TD226B-6D | TBD226B-6D | TDB226B-6D5 |
| Rated Output(kw) | 30 | 40 | 40 | 60 | 90 | 120 | 132 | |
| Max.Output(kw) | 33 | 45 | 45 | 66 | 99 | 132 | 145.2 | |
| Starting Method | Electric Starting | |||||||
| Cooling Method | Colsed Water Cooled | |||||||
| Governing Method | Mechanical | Electronic | ||||||
| Admission Method | Natural | Turbocharged | ||||||
| Cylinder Numbers | 3 | 4 | 6 | |||||
| Fuel Consumption (g/kw.h) | ≤208 | ≤205 | ||||||
| Bore/Stroke(mm) | 105/120 | |||||||
| Displacement(L) | 3.12 | 4.16 | 6.23 | |||||
| Oil Volume(L) | 7.25 | 13 | ||||||
| Type | Water cooling, in-line, four-stroke, humid cylinder liner, direct injection | |||||||
| Alternator | Model | TFW2-24 | TFW2-30 | TFW2-40 | TFW2-50 | TFW2-75 | TFW2-100 | TFW2-120 |
| Rated Output kw(KVA) | 24(30) | 30(37.5) | 40(50) | 50(62.5) | 75(94) | 100(125) | 120(150) | |
| Rated Current(A) | 43.2 | 54 | 72 | 90 | 135 | 180 | 216 | |
| Rated Voltage(V) | 400V/230V | |||||||
| Frequency(HZ) | 50/60HZ | |||||||
| Power Factor (COS ) | 0.8/1.0 lagging | |||||||
| Phase/Connection | 3-phase 4-wire Y type connection | |||||||
| Excitation | Brushless Excitation | |||||||
| Voltage Regulation | Automatic | |||||||
| Net Weight(kg) | 700 | 710 | 720 | 830 | 1350 | 1500 | 1650 | |
| Packing Size LWH(cm) | 170x75x150 | 200x75x150 | 250x95x175 | 250x95x185 | 265x95x185 | |||
| NOTE: | Specification Changed Without Notice, Please Reconfirm Before Finalization. | |||||||
| We can also offer orihinal Leroy-somer, Stamford and Marathon alternator. | ||||||||
Our generator has been exported to South America, Europe, the Middle East, and Africa with supreme quality and after-service by amount about 10 million dollars last year. Especially Bangladesh and Philippines.
Guarantee For One Year Or 1200 Hours (According To Whichever Reaches First)From Ex-Factor During The Guarantee Period, We Will Offer Free-Of-Charge Spares In Case There Is Any Damage Caused By Defects Of Our Goods. We Also Supply Charge Spares After Guarantee Period Or Damage Created By End Customers.
Organized by ISO9001:2008 management system and inspected by Entry-Exit Inspection and Quarantine Bureau. We have passed and work in full compliance with CE, UL.EPA. The following picture of CE certification is for your reference. For more certificates information, please log to Certificates.
A: Irrevocable L/C At Sight
B: T/T (30 Percent In Advance And 70 Percent Before Shipment)
C: D/P at Sight (Only For Specified Customers)
