Wholesale 63kva 50kw Low Price Soundproof Diesel Generator for Home by China Engine 3phase Output
US$ 6,100 - 6,300
/ Set
3 Sets(Min. Order)
- Fuzhou
- T/T L/C D/P D/A Credit Card
You May Like
-
ISO9001 Approved Shangchai 120kw 150kva Electric Diesel Power Generator 50hz 60hz 3phase Soundproof
-
Manufacturer Competitive Price 150kw 187.5kva Silent Type Soundproof Diesel Generator Price List
-
Cheap Turbo Charging Soundproof Big Power 812kva 650kw Generator Set for Sale by China Engine
-
Soundproof 700kw 875kva Diesel Power Generator With 100% Copper Brushless Alternator
-
High Quality 30kw Factory Perkins Generator Price List Engine Made in UK
-
Competitive Price 50kva Perkins Diesel Engine Made in uk 40kw Diesel Generator Set
Product Details
| Place of Origin | Fujian, China | Brand Name | Shanghai diesel | |
| Model Number | GF-50 | Output Type | AC Three Phase | |
| Speed | 1500rmp | Frequency | 50/60HZ | |
| Rated Power | 50kw/62.5kva | Rated Voltage | 400V/230V Adjustable | |
| Rated Current | 90A |
Product Description
Wholesale 63kva 50kw low price soundproof diesel generator for home by china engine 3phase output
| Genset Information | |||
| Model | GF-50 | Net dimensions (mm) | 1800*800*1400mm |
| Prime Output(kw/kva) | 50kw/62.5kva | Standby Output(kw/kva) | 55kw/68.75kva |
| Rated current(A) | 90A | Standby current(A) | 99A |
| Gross weight (kg) | 950kg | Net weight (kg) | 900kg |
| Rated voltage(V) | 400V/230V | Noise (dB) | 100dB(A) |
| Fuel Comsuption (g/kwh) | 207g/kwh | Frequency (HZ) | 50HZ/60HZ |
| Steady voltage adjusting rate | ≤±1% | ||
| Transient voltage regulation | +20~--15 % | ||
| Voltage settling time | ≤1s | ||
| Steady State rate adjustment frequency | ≤±1% | ||
| Frequency fluctuation rate | ≤±0.5% | ||
| Transient frequency regulation | +10~-7% | ||
| Frequency recovery time | ≤3s | ||
| Generator configurations | |||
| Engine Brand: | Shangchai | Fuel Injection | Direct Injection |
| Engine Model: | SC4H950D2 | Bore (mm) | 135*140mm |
| Intake System | Natural aspirated | Cylinder No. | 4/L |
| Cooling method | Closed circulating water cooling | Speed | 1500rpm |
| Compression Ratio | 16.5:1 | Governor | 110% |
| Starting mode | DC24V electrical starting | Speed adjustment mode | Electronic speed control |
| Alternator configurations | |||
| Alternator Brand: | Fengfengsheng | Protection Grade | IP22 |
| Alternartor Model: | TFW-50 | Connect method | Three phase four wire type y connection |
| Rated output (kw/kva) | 50kw/62.5kva | Excitation method | AVR(Automatic voltage regulator) |
| Rated voltage(V) | 400V/230V | Frequency (HZ) | 50HZ/60HZ |
| Insulation Grade | H Class | Power Factor | COS=0.8 |
