LS VISION Professional 360 Degree Ip Camera Video Camera,Full HD 360 Degree Rotation Webcam

Specifications

Product model

LS-SPD5200(5x2MP)

LS-SPD5300(5x3MP)

LS-SPD5500(5x5MP)

Media Processor

High-performance Hisilicon DSP

Image Sensor

5*1/1.9" 2MP Pixel can CMOS

5*1/2.8" 3MP Pixel can CMOS

5*1/1.8" 5MP Pixel can CMOS

shutter speed

1/5 second -1/50,000 second

Min illumination

color:0.1Lux @ F1.2 AGC On

black-and-white:0.001Lux @ F1.2 AGC On

color:0.3Lux @ F1.2

black-and-white:0.005Lux@ F1.2

color:0.2Lux @ F1.2 AGC On

black-and-white:0.003Lux @ F1.2 AGC On

Lens

2.8mm Fixed Lens

viewing angle

360 degree

Day&Night

ICR Infrared filter

Encoding standard

Video encoding standard

H.265/H.264/MJPEG Optional

Encoding type

H.265/H.264 Baseline/MainProfile/HighProfile Optional

Audio coding standard

G.711a/G.711u/RAW_PCM Optional

Image index

Max image size

16 Megapixels / 5 x 1920x1080 (HDTV)

24 Megapixels / 5 x 2048x1520 (HDTV)

40 Megapixels / 5 x 2592x1944 (HDTV)

ePTZ

Support digital zoom / PAN / tilt

frame rate

5 x 1920x1080 @ 30fps

5 x 2048x1520 @ 30fps

5 x 2592x1944 @ 30fps

Image set

Brightness, contrast, saturation, sharpness adjustment

Network function

Smart alarm

Motion detection, occlusion alarm, full of memory, the memory fault.

Support protocol

IPv4/IPv6,RTSP/RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,FTP,DDNS,PPPoE,SMTP,Onvif V2.4

General functions

A key recovery, anti flicker, double stream, heartbeat, password protection

Function interface

network interface

1 RJ45 10M/100M adaptable Ethernet ports

Built-in SD card

Support Max 128G Micro SD/SDHC /SDXC card local storage

Audio input / output

1- channel 3.5 mm audio input (mic input / linear input) / output interface

Alarm input / output

1 channel input / output

General specification

working temperature/humidity

-30℃ ~ 60℃, humidity is less than 95% (no condensation heater).

Power Interface

DC12V±10%,3A

Power

36W

Waterproof Rate

IP66

Vandal-proof Rate

IK10

Dimensions(mm)

281.8 x 228mm

Weight(kg)

5.9
