Home > Products > Sonar Device > Sonar Fish Finder TF500 Sonar Device
Sonar Fish Finder TF500 Sonar Device
- qingdao China
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | haoyazhi | |
| Model Number | TF500 | Type | Other, fish finder |
Product Description
Sonar Fish Finder TF500 sonar device
| Specification and Feature | ||
| Specification | Display | Display Size:4.3"TFT LCD;Sunlight Viewable |
| Resolution:480*272 Pixels;65,536 color | ||
| Language:Multi-language | ||
| Monitor and Display Real-time Voltage of Bait Boat Battery | ||
| IPX6 Level Waterproof Casing Design | ||
| Sonar | Depth Capability:30m(100ft) | |
| Sonar Frequency:115khz | ||
| Sonar Beam Angle:60deg@-10db | ||
| Sonar Alarm:Fish/Shallow/Low Battery | ||
| R/F | RC Distance(field test):Max 300m(1000ft) | |
| Ridao Frequency:2.4Ghz | ||
| RF Channel: 20 | ||
| RC Power:20dBm | ||
| Power | Power of Display:6-12V Lithium Battery or 8*AA Battery | |
| Power of Transmitter:Powered by Bait Boat or DC 6-12V/2.0W | ||
| Technical and Casing | Senor Cable Length:0.5m | |
| Sonar Unit Size:153*110*44mm;Potable Case Size:262*150*98mm | ||
| Opterational Temperature:-10℃-50℃ | ||
| Water Temp. Included in Transducer | ||
| Features | Extreme stable wireless performance even in bad condition | |
| Display targe dephth reading above each fish symbol | ||
| Big/small fish identification | ||
| Rugged potable case for a full protection of the fish finder | ||
| Full one-year warranty;extened warranties avaiable | ||
| Menu List | ||
| Basic | Sensivity | Controls the level of details shown on the display |
| Fish ID. Sens. | Adjust the threshold of fish size display,higher setting allows weak returns being displayed as fish,while a low setting will prevent it being displayed as fish | |
| Depth Range | Determine in which portion the bottom will be displayed on the screen | |
| Night Mode | Set the background to black and dimming the backlight automatically | |
| Advanced | RF Channed | Set different RF channel to allow more than one users operating the device in the same region without any radio interference |
| Backlight | Adjust the brightness of backlight | |
| Background | Change the background of the screen | |
| Color Scheme | Set displaying bottom in color mode or in sandy style | |
| Color Line | Separates strong sonar echoes from weak sonar echoes. That makes it easier for you to distinguish fish for structure from the bottom. | |
| Beeper | Set if the sonar unit sound a tone or not when a key is pressed | |
| Fish Alarm | Fish alarm sounds when the fish finder detects what it determines to be a fish | |
| Shallow Alarm | Sounds when the depth becomes equal to or less than the menu setting | |
| Battery of Display | Sounds when the input battery voltage of display is equal to or less than the setting | |
| Battery of Boat | Sounds when the input battery voltage of transmitter is equal to or less than the setting | |
| Measure Units | Set the units of measure for all depth-related readouts | |
| Language | Select the display language for menus | |
| System Reset | Used to retore original factory setting | |
| Simulator | Used to let you practicing using the fishfinder as if you were on the water | |
| System info. | Show syetem information of device | |
| Baud Rate | Used to control data transmission with external device | |
1.Show water temperature and air temperature
2.Detection of underwater topography and depth of water.
3.Big/small fish identification.
4.Fresh/salt water environment.
5.Sonar alarm:fish/shallow/ Low battery
Product Quality Side
100 % double quality check before shipment (QC check the quality as factory standard and testing the boat in the reservoir).
Service Side
1.Any inquiry will be replied within 24 hours.
2.One stop service and after service consistence.
3.Skilled technology team to service for all global customers.
Payment and Shipment Side
1.Payment term :T/T L/C Western Union Paypal Credit Card.
2.Shipment term:by air, by sea, by train.
3.Delivery time: 3-5 days for sample order, 15~20 days for bulk order.
Maintenance
With a view to making use of your Fishfinder,we recommend you follow the steps bellow and carry out maintenance.
1. For the case
Cleaning the sonar unit's outer case(except for the screen)with a cloth dipped mild detergent solution,and then wipes it dry.
2.For the screen
Use a piece of soft cloth or pelt to clean the screen (fresh water or eyeglass cleaner can be used if needed).Stubborn dirt or oil stains remaining on the screen shall not be wiped with force;otherwise it may scratch the surface.
Additionally,give daily attention to ensure the screen is keep for any chemicals.
