3kw 200Hz Inverter Generator for Airport

FOB Price

US$ 300 - 500 / Set

100 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1. Rare earth permanent magnetic for rotor.

2. 100%COPPER wire winding for stator.

3. Brushless and easy maintaince.

4. Digital inverter to insure stable voltage and frequency.

5.Reliable quality, 100% warranty, variable speed but stable frequency and voltage

6.specification:

Model	CT-1.8	CT-3	CT-5	CT-7.5	CT-10
Rated voltage	230V
Rated current	7.8(A)	13.0(A)	21.7(A)	32.6(A)	43.4(A)
Rated power@1800rpm	1.8(KW)	3(KW)	5(KW)	7.5(KW)	10(KW)
speed	500-3000rpm
Frequency	50/60(Hz),200/400(Hz)
Brush/Brushless	Brushless
Output wave	Pure sine wave,waveform distortion rate≤1.5%
Efficiency	≥90%
Voltage rate	±2%
Protect Class	IP21
The electronic control	digital inverter
Insulation Class	H
GW	20.6(Kg)	21.8(Kg)	23.0(Kg)	47(Kg)	47(Kg)
NW	20.1(Kg)	21.3(Kg)	22.5(Kg)	42(Kg)	42(Kg)
Foot	182×90(MM)	182×90(MM)	182×90(MM)	232×108(MM)	232×108(MM)
Height of center	126(MM)	126(MM)	126(MM)	146(MM)	146(MM)
Screw	M12	M12	M12	M12	M12
Axis diameter	32(MM)	32(MM)	32(MM)	38(MM)	38(MM)
Dimension	320230320(MM)			370290372 (MM)
Marks	PMA+INVERTER=2 in 1 complete set,speed and voltage protect for selection

100% copper wire

Digital Inverter

Indication Panel
