12V 300LED IP66 5050 Pink Waterproof Flexible LED Strip light

FOB Price

USD $1 - $3 / Meter

1 Meter(Min. Order)

Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

LED Light Source	5050	Type	Flex LED Strips
Input Voltage(V)	12	Lamp Power	72
Lamp Luminous Flux(lm)	12-14	Working Temperature(℃)	-10, +45
Working Lifetime(Hour)	50000	Lamp Body Material	Aluminum
Certification	CE	Emitting Color	White
Place of Origin	Guangdong, China	Brand Name	OGX
Model Number	ST50W60D66

Product Description

Specifications

DC12V
300LED per 5meter
IP66 5050 Pink Waterproof
Warranty:2years
Life:50000hours

White Silicon Tube Cover waterproof IP66 DC12V/DC24V 60LEDs/m 5050 Flexible LED strip light

The STAR FLEX STRIPS are perfect for indirect lighting, as custom made versions for fair or shop applications as well as for all kinds of illumination. Due to their shallow design and the individually adaptable lengths the STAR FLEX STRIPS offer a wide spectrum of application possibilities.

1.3 colours on one chip, therefore 100% smooth colour mixing.
2.High flexibility – adaptable to round shapes.
3.Installation with 3M adhesive tape on the strip’s backside (self adhesive).
4.dimmable, autom. colour change, DMX 512, 1-10 V controllable by RGB MULTI power supplies/controller

5050 12V 60led cuttable length:

Technical Data:

IP classification	IP66 for outdoor
Working current	1.2A
Power source	12 VDC Common Anode (CA)
Electrical connection	2x cable with 4-PIN to open wires
Maximum quantity per power input	5meter
Operating temperature range	–10° C till +45° C
Width x height	10 x 2,5 mm
Cuttable	all 3 LEDs (5 cm)
Wattage	14.4w/m,72w per 5meter

Photometric Data:

LED type	SMD RGB 3-in-1 LEDs
Luminous flux	red 70 Lumen per m green 220 Lumen per m blue 50 Lumen per m r+g+b (white) 330 Lumen per m
Wave length	red 623 nm green 525 nm blue 464 nm
Beam angle	120°

ACCESSORIES

Supply connector to open wires
