stainless steel pipe water jet cutting machine

FOB Price

US$ 32,000 - 45,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	MUNAN CNC		Model Number	MN4235-NC1520-I
After-sales Service Provided	Engineers available to service machinery overseas

1.Good qulity waterjet cutting machine low cost
2.Suitable for marble,galss,stainless steel
3.the Cutting accuracy is 0.05mm

Water jet cutting machine MN4238-NC2015-II

Special flying arm structure, be easier to load and unload materials.
Split-type structure makes installation and maintenance more convenient.
The whole casting body makes equipment steady, X&Y axis adopt high precision ball screw and linear guide, and advanced multi-level protect design which guarantee transmission’s reliability and good accuracy.

All of these models can be customized according to customer requirements.

NC series	NC1313-I	NC2015-I	NC2515-I	NC3020-I			NC6020-I
Table size/m	1.3*1.3	2.0*1.5	2.5*1.5	3.0*2.0			6.0*2.0
Optional working area	Weight of the machine: 1.3m/1.5m/1.8m/2.0m Length of the machine: less 6.0m
Z axis travel	150mm/210mm
Transmission	X/Y high precision ball screw
Cutting accuracy	±0.05mm
Repeatability accuracy	±0.03mm
Max.Travelling speed	20m/min
Power	220V/380V/415V, 50/60HZ
Drive motors	Servo motors
Controller	PC with controller
software	AutoCAD

Ultra high pressure system			MN-4035			MN-4238
Overall dimension/m			1.71.01.4			1.81.01.5
Supercharge ratio			20:1
Continuously working pressure			350MPa/ 50K Psi		380MPa/ 55K Psi
Max. pressure			400MPa/ 58K Psi		420MPa/ 60K Psi
Max. Water yield			3.7L/min
Water supply pressure			≥0.2MPa
Oil pump pressure			31.5MPa
Hydraulic oil tank capacity			46#/320L
Max diameter of nozzles gemstone			0.35mm
Power			37kw
Power supply			220V/380V/415V, 50/60Hz

1.Ultra-high pressure generator and cooling system of type MN-4235

2. Integral cutting head and ultra-high pressure pipeline

3. Automatic abrasive transportation system

4. CNC servo machine tool -NC 2015-II

4.1 User can load and unload the parts from three directions

4.2 Drive motors and transmission sysem

4.3 Stainless steel water tank

4.4 stainless steel dust proof.

4.5 Steel strucure:

5. pulse generator and controller box

6. Cooling tower and spare parts
