Single Man Barrier Free Lift for Home Use
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Disable People Used Vertical Wheelchair Platform Lift
-
1m Home Used Vertical Wheelchair Lift for Old Disabled People
-
Good Quality Elderly Lift With no Obstacles Price
-
Best Price Hydraulic Barier Free Lift
-
Convenient Vertical Barrier Free Stair Lift for Home Use
-
Portable Wheelchair Free Lifting Platform
Product Details
| Place of Origin | Shandong, China | Brand Name | Truewin | |
| Model Number | LRL0.25-2 | Lift Mechanism | Lift Chain | |
| Lift Drive / Actuation | Hydraulic | Power | 2.2kw | |
| Rated Loading Capacity | 250kg | Min. Lifting Height | 1m | |
| Max. Lifting Height | 6m | Table Size | 1220mm*915mm | |
| Overall Dimensions | 1200mm(L)*1400mm(W)*4600mm | Weight | 350kg | |
| Certification | CE&ISO9001:2000 | Warranty | one year | |
| After-sales Service Provided | Overseas third-party support available |
Product Description
Single man barrier free lift for home use
We can according to your needs, provide special design and customize products for you , send engineers guides installation and after sale repair overseas.
Packaging Details : Plywood case or manual packing
Shipping Details : Within 15 working days after receiving the deposit.
Single man barrier free lift for home use
Specification
Capacity : 350kg
Loading capacity : 250kg
Lift speed : 6mm/s
Lifting height : 6m
Indroduction
1. Automatic running: without human intervention , fold automatically,back to original position
2. Manual control system: manual mode switch can control the auxiliary system manually
3. Running alarm, voice and light.
4. Acceleration&Deceleration automatically: when the plat will reach the station, it can acceleration&Deceleration automatically
5. Not running when incorrect operating
6. Not running when Safe step pedal and closure can not take the right position
7. Stop running when sensor operated(Non touch type and touch type) until the obstacle be moved away.
8. Abnormal operation protect system.
9. Limited position protect system
10. Current overload protect system
11. Emergency stop system
Technical Parameter
| Configuration | Open through or front and side entrances |
| Speed | 60mm/s |
| Load Capacity | 250KG |
| Control Voltage | 24V/DC |
| Power Output | 0.75kw-2.2kw |
| Power Input | 220v/50HZ/25A(or customized for local power supply) |
| Drive System | Hydraulic |
| Control Mode | Inching Switch or Automatic |
| Drive Control | Self-resetting system |
| Material of platform | Stainless steel |
| Guard Panel&Drive | 304stainless steel |
| Cabinet(framework) | |
| Automatical ramp | Yes |
| Column Switch | Two column switch, one is on the ground floor, one on the first floor |
| Operation Panel | Polished Stainless steel(up down and Emergency drop valve) |
| Safety Wane Working Range | 75° |
| Working Condition | Both indoors and outdoors |
| Working temperature | From -10°-60°c |
| Installation | Non-pit installation, directly fixed to concrete floor(the concrete floor below the platform shall not be lower than the ground) |
| Control Device | Calling box(installed on the wall nearby) and remote controller(Extral optional) |
| Emergency Stop | The lifting and lowering process can be stopped immediately by pressing the emergency button |
| Safety Device | Safety Inter lock :Lock the platform when it is out of control |
| Safety Sensor:the operation must be stopped immediately the safety edge meets obstacles during operation | |
| Emergency lowering: the platform can be lowered by opening hydraulic valve manually or rolling screw rod. | |
| Auto-flap: Turn up after lifting |
Features
---Novel design
---Perfect stability and safety
---Nice appearance
-- Vertical barrier free stair lift can save labor work and promote the efficiency ,safely and conveniently.
-- Vertical barrier free stair lift is operated easily with electricity and hydraulic power
-- Electric control, hydraulic driving, which make it easy and reliable operation.
-- The lip connected with the platform with a whole bearing, reliable and high intensity.
-- The O-rings in pistons are imported from Japan so to insure the vacuum of hydraulic system
-- Imported hydraulic pump valve to insure a stable operation and long life.
-- The lip clinging with the car all the time which makes the convey cart moves very easily.
-- For special contractures, we provide special design and order
Application
barrier free lift is widely used in residential areas, hotels, administrative offices buildings, subways, banks, stadiums, hospitals and other public places
| | | |
| CE electric platform outdoor wheelchair lift | China hot product telescopic boom lifting platform | Hot sale cheap guide hydraulic cargo rail lift platform | China factory Jinan hot sale mobile yard ramp |
| Lifting height: 6 m | Lifting hieght: 16m | Lifting height: 5 m | Lifting height: 1.7m |
| Loading capacity: 250 kg | Loading capacity: 160kg | Loading capacity: 2T | Loading capacity: 10T |
Shandong True Win Construction Material Co.,Ltd is a professional manufacturer of aerial working platforms.
The main products in our factory including : Mobile scissor lift, Stationay scissor lift, Self-propelled scissor lift, car-carring scissor lift, Alluminum alloy hydraulic lifting platform, Guide rail lift, hydraulic lifting dish conveyer, hydraulic articulated boom lift, hydraulic lifting stage, statioanry yard ramp, mobile yard ramp, 4 car lifting machine, hydraulic cylinder lift platform and barrier free lifting platform.
They are widely used in factories and docks, such as plant maintenance, industrial installation, equipment's repair property management, warehouse, airport, port, station, gas station, stadium, museum, exhibition hall.
Our products are sold 30 countries around the world, mainly in Europe , south-Africa ,middle-east,south-east Asia,USA and south-africa.
FAQ:
Q:Who are you? Trade Company or manufacturer?
A: We are manufacturer and we have our own trade company.
Q: When the product can be delivered?
A: Commonly the lead time will be within 15 days after payment.
Q:What’s the Min order to your company?
A:1 set.The sample order, if we have stocks, we will send out the products within 1 week.
Q:What’s the advantage of your company?
A:We have exported our lifts and service to more than 100 countries. We have speclized team work for you, you will get our feedback within 24 hours./ Germany and Italian advancedmanufacturering technology.
Q:What need you know when i inquiry to you ?
A: We need to know your Max Capacity,Platform size and Lift height.
