Home > Products > Optical Instrument > TES-133 Luminous Flux Meter With RS232 Datalogger
TES-133 Luminous Flux Meter With RS232 Datalogger
- Shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Taiwan, China | Brand Name | TES | |
| Model Number | TES-133 |
Product Description
TES-133 Luminous Flux Meter
Features
4-digit LCD reading.
Spectral Sensitivity close to CIE photopic Curve.
Auto ranging from 0.05 to 7000 lumens.
Accurate and Instant response.
Data Hold function.
Data memory and read function.
Zero function.
Ratio function.
Sort function.
Comparator function.
Best for measuring : LEDs, Small lamps, Fiber illuminators.
Auto power off function.
RS232 Interface.
Easy to use.
Adapters kit : 2/3/4/5/8/10m/m
Specifications:
Display | 4 digit LCD read out | |
Measuring Range | 9.999, 99.99, 999.9, 7000 lumens, Auto ranging (4 step) | |
Overrange Display | OL is displayed | |
Resolution | 0.001 lumens | |
Accuracy | 0.05 to 0.1 ±7%, 0.1 to 1000 ±1%, 1000 to 7000 ±3% | |
Integrating Sphere | Diameter | 50mm |
Sample pore | 12.7mm diameter | |
CIE photopic f ’1 | </=6% | |
Temperature Characteristics | ±0.1%/°C | |
Measuring Rate | Approximately 5 time/sec | |
Photosensor | Silicon photodiodes | |
Data Memory Capacity | 999 sets. (Direct reading from LCD display) | |
Data Logger Capacity | 40000 sets | |
Operating/Storage Conditions | 0°C ~ 50°C <80% RH , -10°C ~ 60°C <70%RH | |
Power Source | 6 pcs AAA size Battery | |
Battery Life (typical) | 100 hours | |
Integrating sphere Lead Length | 150 cm (approx.) | |
Integrating sphere Dimensions | 68(Diameter) × 82(H)mm | |
Dimension | 150(L) × 72(W) × 35(H)mm | |
Weight | 470g | |
Accessories | Carrying case, Instruction manual, Battery, CD software, RS232 cable, AC adaptor, Adapter kit. | |
