baofeng UV-5RC 5W 128CH portable UHF VHF Dual band Radio baofeng

All of our items are Brand New

Model

BF-UV5RC

Basic Descriptions

Rated Voltage

7.4V DC±10%

Output power

≤ 5W

Battery type

Li-ion battery

Battery capacity

1800mAh

Working temperature

-20~+50 degree

Inductively loaded antenna

Yes

Antenna Impedance

50Ω

Weight

255g

Dimension(L×W×H)

58×32×110mm(Not Antenna)

Hot Spots

Dual band or Single band

Dual band, A/B band independent operation(UV UU VV)

Dual frequency or Single frequency

Dual frequency

Frequency Range

UHF: 400-520 MHz + VHF: 136-174 MHz

FM radio

Yes(65-108 MHz)

Memory Channel

128

Working manner

Simple or semi-duplex

Channel step

2.5/5/6.25/10/12.5/25kHz

CTCSS/DCS function

50 CTCSS/105 DCS

DTMF function

Yes

OFF SET function

Yes

Wide/Narrow Band(25kHz/12.5kHz)

Yes

VOX function

Yes

Emergency Alarm function

Yes

Busy lockout function

Yes

Scanning function

Yes

Monitor function

Yes

Time-out Timer (TOT) function

Yes

LCD display

Yes

Dual display

Yes

Battery voltage display function

Yes

Channel name display and editing functions

Yes

Signal strength indicator

Yes

Keypad lock function

Yes

Built-in Led torch

Yes

Wire clone function

Yes

Emergency alarm function

Yes

Low battery alarm

Yes

Power saving function

Yes

High/Low TX power selectable

Yes(5W/1W)

ROGER SET

Yes

Chinese and English voice prompt

Yes

PC software programmable

Yes

Specification

Frequency stability

±2.5ppm

Carier wave tolerance

5ppm

Modulation

16kΦF3E / 11kΦF3E

Max frequency deviation

< 5kHz(Wide) < 2.5kHz(Narrow)

Modulation character

6 dB per fold frequency patch

Emission current

< 1.6A(5W)

CTCSS / DCS

0.5±0.1kHz(Wide) 0.3±0.1kHz(Narrow)

Sensitivity

< 0.16μV(12dB SINAD)

Silent sensitivity

< 0.2μV

Intermediation Distortion

<10%

Inter modulation

8-12mv

Adjacent channel selectivity( wide/narrow)

<-65dB(Wide) <-60dB(Narrow)
