Home > Products > Digital Multimeter > Economical Portable Digital Multimeter, AC/DC/Resistance/Capacitance/Inductance/Temperature UT50D

Economical Portable Digital Multimeter, AC/DC/Resistance/Capacitance/Inductance/Temperature UT50D

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	UNI-T
Model Number	UT50D	Measuring Current Range	20mA/200mA/20A
Measuring Voltage Range	2V/20V/200V/750V	Measuring Resistance Range	200Ω/2kΩ/200kΩ/2MΩ/20MΩ
Measuring Capacitance Range	20nF/200nF/2μF/100μF	Measuring Inductance Range	2mH/20mH/200mH/20H
Dimensions	165mm80mm38.3mm

Specifications:

Specifications	Range	Best Accuracy
Model		UT50D
DC Voltage (V)	200mV/2V/20V/200V/1000V	±(0.5%+1)
AC Voltage (V)	2V/20V/200V/750V	±(0.8%+3)
DC Current (A)	20mA/200mA/20A	±(0.8%+1)
AC Current (A)	20mA/200mA/20A	±(1%+3)
Resistance (Ω)	200Ω/2kΩ/200kΩ/2MΩ/20MΩ	±(0.8%+1)
Capacitance (F)	20nF/200nF/2μF/100μF	±(2.5%+5)
inductance (H)	2mH/20mH/200mH/20H	±(2%+10)
Temperature (°C)	-40°C~1000°C	±(1%+30)
Features
Full Icon Display		Yes
Diode		Yes
Continuity Buzzer		Yes
Low Battery Display		Yes
Input Impedance for DC Voltage Measurement	10MΩ	Yes
Data Hold		Yes
Display Backlight	Auto	Yes
Max. Display		1999
Auto Power Off		Yes
General Characteristic
Power	9V Battery (6F22)
LCD Size	95mm×25mm
Product Colour	Red and Grey
Product Net Weight	275g
Product Size	165mm×80mm×38.3mm
Standard Accessories	Test Lead, Battery, Test Clip
Standard Individual Packing	Gift Box,English Manual
Standard Quantity Per Carton	40 Pcs
Standard Carton Measurement	588mm×408mm×326mm
Standard Carton Gross Weight	20kg
Optional Accessories*	Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2)

Contrast:

Specifications	Range	Best Accuracy
Model		UT50D	UT50E
DC Voltage (V)	200mV/2V/20V/200V/1000V	±(0.5%+1)	±(0.05%+3)
AC Voltage (V)	2V/20V/200V/750V	±(0.8%+3)	±(0.5%+10)
DC Current (A)	20mA/200mA/20A	±(0.8%+1)
DC Current (A)	2mA/20mA/200mA/20A		±(0.5%+5)
AC Current (A)	20mA/200mA/20A	±(1%+3)	±(0.8%+10)
Resistance (Ω)	200Ω/2kΩ/200kΩ/2MΩ/20MΩ	±(0.8%+1)
Resistance (Ω)	200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ /200MΩ		±(0.3%+1)
Capacitance (F)	20nF/200nF/2μF/100μF	±(2.5%+5)
Capacitance (F)	2nF/20nF/2μF/20μF		±(3%+40)
inductance (H)	2mH/20mH/200mH/20H	±(2%+10)
Temperature (°C)	-40°C~1000°C	±(1%+30)	±(1%+30)
Frequency (Hz)	20kHz		±(1.5%+5)
Features
Full Icon Display		Yes	Yes
Diode		Yes	Yes
Continuity Buzzer		Yes	Yes
Low Battery Display		Yes	Yes
Input Impedance for DC Voltage Measurement	10MΩ	Yes	Yes
Data Hold		Yes	Yes
Display Backlight	Auto	Yes	Yes
Max. Display		1999	19999
Auto Power Off		Yes	Yes
General Characteristic
Power	9V Battery (6F22)
LCD Size	95mm×25mm
Product Colour	Red and Grey
Product Net Weight	275g
Product Size	165mm×80mm×38.3mm
Standard Accessories	UT50D-Test Lead, Battery, Test Clip
Standard Accessories	UT50E-Test Lead, Battery, Point Contact Temperature Probe, Test Clip
Standard Individual Packing	Gift Box,English Manual
Standard Quantity Per Carton	40 Pcs
Standard Carton Measurement	588mm×408mm×326mm
Standard Carton Gross Weight	UT50D-20kg,UT50E-20.5kg
Optional Accessories*	Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2)

Accessories:

Test Lead,
Battery,
Test Clip
Clip-On Test Lead Light (UT-TL)*,
Built-In Test Lead Light (UT-L1)*,

Built-In Test Lead Light Plus (UT-L2)*
