Concrete Cooling Systems-Qatar Project

Specifications

Snowkey Concrete Cooling Systems consists:

ntainerized ice machine,

2.water chiller ,

3.automatic ice sorage bin,

4.delivery system,

5.weighing hopper.

Features of the system

(1) Small size, small area, convenient transportation

(2) Rapid installation, adaptable to adverse surroundings

(3) Fully automatic control, convenient operation and maintenance

(4) easy and convenient to operate, and adaptable to adverse surroundings, works at the ambient temperature ranging from -30 ^.C to 56 ^.C.

Advantages of flake ice

Flake ice is  flat in shape, which can be applied to seafood cooling, meat processing and industrial procedure. The most important use of SNOWKEY flake ice is concrete cooling, especially in hot climate. Though the flake ice is cooled down slightly-7, it is still a kind of dry ice, which means its heat quantity is potential and the main source of cooling energy can be 100% guaranteed. Since it is a kind of dry ice, the cooling input of flake ice can be calculated accurately and the temperature effect to the concrete mixture is obvious. Flake ice is movable freely. They will not stick together, and condense to lump. Therefore, flake ice is convenient to store and transport. Because of the above features and moderate production cost, flake ice is greatly applied to many industries and food processing.

Carry-out standard

1.White painted new container with air conditioner, illumination and aluminum door, meeting the International Organization for StandardizationISOrequirement

2.piston and screw compressor

3.motor IP55 insulation class F

4.1set of evaporative condenser

5.1 set of ice maker with ice level control

6.automatic oil return system

7.water flow controller with ice maker indicator light

8.switch and control panel for automatic operation

9.stainless steel panel with stainless steel meters

10.assemble, pipeline and circuitry meet German standard
