Rake Type Automatic Ice Storage (75Ton)

Specifications

Automatic Ice Storage
Store the ice produced by ice maker. When a large amount of ice is demanded in a short time, the ice storage can deliver the ice automatically. During operation, the ice produced will be leveled inside the ice storage. When the ice stored reaches the upper limit, the ice maker will be stopped automatically. And the ice maker will be restarted when the ice level is lower.

SNOWKEY automatic ice storage, which is simple to install and moveable, falls into two types: containerized and combined type with ice storing capacity ranging from 18 ton to 200 ton. The containerized one is installed inside 40 feet container. The factory-install ice storage is easy to transport by truck, railway and ship. Therefore, they are especially applicable at remote area or where the ice making equipment will be moved from one site to another usually.

Product Features
1. The ice storage is specially designed with double-layer insulated layer. There is an air circulation layer around the ice, even when the ice storage is full of ice. There is a cooling device equipped to keep the ice storage temperature at -8°C, which will keep the ice dry and soft.

2. SNOWKEY automatic ice storage adopts heavy industrial components, which are all seriously selected, to ensure continuous run, long lifespan and low maintenance cost.

3. The ice raker of the automatic ice storage, which has compact structure and stable continuous run, adopts high strength special material.

4. The hoister can adjust the height of the ice raker automatically to ensure the ice raker is always above the ice surface.

5. The ice bin door, which is equipped with a carrier, can be opened and closed automatically. Through the ice bin door, you can observe the ice level inside.

6. All devices and standard parts inside the ice storage are hot galvanized. We have stainless steel as option.

7. The automatic ice storage has two ice outlets. We have one-way and two-way ice outlet for your option. All systems are equipped with pneumatic ice delivery system or screw ice delivery.The control panel adopts PLC and touch screen, including short circuit protect, variable-speed drive for the ice raker elevation, humanized operation interface and alarm system.

8. Computer monitor and technical support, which is carried out by computer remote control and modem.

9. All maintenance spare parts have inventory and standard parts can be delivered all around the world on the same day.

Main Components Of SNOWKEY Ice Storage
1. The ice storage bin is made up of reinforced base plate, sidewall plate, end wall plate and top plate. There is insulated material layer(polyurethane foam), 100mm in thickness,  inside the plate

2. The wallboard contacting with ice inside the ice storage is galvanized sheet. Stainless steel sheet is optional. Between the bin plate and the galvanized sheet, there is cold air passage.

3. At the two ends of ice storage bin, there is stainless steel insulated bin door for entering and maintaining the ice storage bin.

4. The ice raking device is hot galvanized. The material of the ice raker and the annular chain is hard alloy.

5. The elevating device is hot galvanized with modular structure. It is automatically operated and should be kept above the ice surface. The ice raking frame can be adjusted according to the height of ice level detected.

6. Regarding the bin door, there are dynamic and pneumatic type carriers for your option. Below the bin door, there is a horizontal screw with two separate ice outlets (the outlet gate is automatically or manually opened and pneumatically operated), which can deliver ice at the same time or separately.

7. The air cooling fan inside the ice storage bin will keep the temperature of the ice storage bin at -8°C, which will keep the flake ice dry.

8. A complete set of switch and control system with connection port for connecting with the control system of the batching plan and remote control.

9. Inside the ice storage bin, there is balance detector for ice raking device, ice full detector for horizontal screw and ice storage and related protect device.

10. There is a monitor system equipped inside the ice storage bin. The camera is installed above the ice bin door and screw delivery for monitoring the running status inside the ice storage.

Performance Parameter
