Newest In-Ground Integrated Swimming Pool Water Filter

Specifications

Newest In-Ground Integrated swimming pool water filter

1>. Description:

Embedded integrated filter can be fixed at a convenient place (underground) near a swimming pool. The filter does not need a machine house, which save construction cost. This filter is characterized by simple installation, complete filter equipment, high performance and conformity to swimming pools specifications. With a durable and corrosion-proof enclosure, the filter can bear 500kg pressure and work well in atrocious weather. These make the filter an outstanding choice for outdoor use.

1)  Complete Filter system

2)  Complete cyclic system

3)  Disinfection system

4)  Time Controller

5)  Cleaning system

2>. Technical characteristics:

Power :  2HP/220V/50Hz  3HP/220V/50Hz

Filter type: Cartridge filter (polyester fiber), 2pcs x 75ft2

Flow rate:  35-36m3/h

Disinfection: chlorine feeder  ,   Salt chlorinator: 15g/h,25g/h,50g/h (Optional)

Installing: Embedded

External controller: with time

Bear 500kg pressure

External Dimension: 1380x1180x1200mm

3>. Features:

1)         Easy to install, save labor cost

2)         Durable & 1 years guarantee

3)         No need machine house, save construction cost

4>. Ideal for:

Small Swimming Pool & Spa Pool (less 400 m3/h)

1)       hotels

2)       Motes

3)       Clubs

4)       Condos

5)       Apartments

6)       Homes

5>. Pictures

1. Inside Parts Picture

2. PK8012 Integrated Pool Filter Inside Looking

3. Install next to the swimming pool

4. Pool with in ground integrative filter

5. Our In ground filter series products

6. Our Office and Exhibition Hall Combo Picture

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Your question will be welcomed, please feel free to contact with us at any time.
