Home > Products > Series CYS Centrifugal oil separator > Moisture and Impurities Cleaning Up, Marine Diesel and Fuel Oil Centrifugal Separator
Moisture and Impurities Cleaning Up, Marine Diesel and Fuel Oil Centrifugal Separator
US$ 8,000 - 25,000
/ Set
1 Set(Min. Order)
- Shanghai/ Chongqing
- T/T L/C D/P D/A
You May Like
-
Water and Impurities Removal, Fuel Oil Mineral Oil Centrifugal Separator
-
Removing Grease/ Sludge Quickly, Lubricant/ Fuel Oil Centrifugal Machine
-
Strong Demulsification Ability, Lubricating/ Fuel Oil Centrifugal Filter
-
Disc centrifugal coconut oil separator, virgin coconut oil centrifuge
-
Series CYS high speed three phase coconut oil centrifuge machine, coconut oil sediment separator, oil centrifuge machine
-
Series CYS high speed three phase centrifugation oil centrifuging machine, oil centrifuge separator
Product Details
| Condition | New | Flow | 100-2500L/H | |
| Working Pressure | 0.4Mpa | Place of Origin | Chongqing, China | |
| Brand Name | TOP | Model Number | KYDH206SD-23 | |
| Usage | Lubricant Oil | Voltage | 380V | |
| Power(W) | 5.5kW | Dimension(L*W*H) | 1250mm*1010mm*1370mm | |
| Weight | 780kg | Certification | ISO CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Product Description
Moisture and Impurities Cleaning Up, Marine Diesel and Fuel Oil Centrifugal Separator
Brief Introduction
The marine separator is mainly used for cleaning up the moisture and mechanical impurity in the fuel (light diesel oil, heavy diesel oil, fuel oil) and lubricating oil of ships and diesel engine, which is good to reduce the abrasion and prolong its sevice-life. The heavy diesel oil is separated by separator can replace the light diesel oil for using so thatreducethecost ofproduction greatly.
The marine separator is mainly used for cleaning up the moisture and mechanical impurity in the fuel (light diesel oil, heavy diesel oil, fuel oil) and lubricating oil of ships and diesel engine, which is good to reduce the abrasion and prolong its sevice-life. The heavy diesel oil is separated by separator can replace the light diesel oil for using so thatreducethecost ofproduction greatly.
Main Technical Parameters
1. Model KYDH206SD-23
2. I.D. ofdrum 350mm
3. Drum speed About7320r/min
4. Counter speed 120r/min
5. Separatingfactor 9510
6. Ratedcapacity ≥3500L/h
7. Motor model Y132S-4B5
8. Power 5.5kW
9. Outlinedimension(L×W×H) 1250mm×1010mm×1370mm
10.Mass 780kg
11.Typeof ejectionsystem automaticdischarge
12.Material ofbowl, hood,frame, solid
The parts which contact with feed is catcher stainless steel
12.Material ofbowl, hood,frame, solid
The parts which contact with feed is catcher stainless steel
Special function of disc separator
4.1 The motor drives gear unit by friction clutch, then the vertical shaft to drive the drum. The friction clutch can guarantee steady starting of the separator, the acceleration is even, and can avoid overload in motor and gear. In order to minimize wear and influence of drum vibration on the whole machine, the vertical shaft will use anelastic bearing structure.
4.1 The motor drives gear unit by friction clutch, then the vertical shaft to drive the drum. The friction clutch can guarantee steady starting of the separator, the acceleration is even, and can avoid overload in motor and gear. In order to minimize wear and influence of drum vibration on the whole machine, the vertical shaft will use anelastic bearing structure.
4.2In order to check whether the separator is run normally, tachometer is arranged, the counter displays the separator speed in rpm. At normal operation, the counter rpm shall meet thevalues in thetechnicalspecifications.
4.3The drum is of high speed and moment of inertia. After turning off the separator, it will take a long time to stop rotation by itself, that’s why brake is furnished to reduce the stopping time, meanwhile it can pass the critical speed of the vertical shaftrapidly. Brakecan alsobe usedfor special case
