Vacuum Kneader Machies

Specifications

This mixer will be in conformity with CE, and its controlling system meets CS standard.

Rated capacity: 350 to 450 kg/batch (soap noodles)

Dosing vessel volume is 400 kg soap noodles.

Two Z-shaped sigma agitators inside the mixing trough the gyration diameter of the agitator is 600 mm, inclination angle 60º.

Motor: 18.5+18.5 kW

Speed: Agitator A  22 r/min

Agitator B  36 r/min

Pressure of compressed air: 0.4 MPa

Consumption of compressed air: 0.5 m3/min

All metallic parts in contact with soap are in stainless steel 304.

The property class of all threaded fasteners will be over 8.8, and with locking devices

The threaded fasteners made from stainless steel the strength of material will not lower than that of A270.

The speed reducers for agitators are supplied by Flender, Germany.

Two discharge gates are with their own air cylinder to open/close the gate. The cylinder is made in Wuxi, China.

All bearings will be the best brands.

The load cells of pressure type and the field weighing controller are supplied by Toledo, Switzerland.

Operation panel is supplied by Rittal, Germany.

PLC by Omron, Japan.
