Medical Tube Making Machine Made in China
- shanghai
 - T/T L/C D/P D/A Credit Card PayPal

You May Like
-


Medical Cap Making Machine Made in China
 -


Medical Disposable Making Machine Made in China
 -


Stainless Steel Water Tank Making Machine Made in China
 -


Small Bottles Plastic Bottle Manufacturing Machines Hot Sale Made in China
 -


China Low Price Small Plastic Bottle Making Machine
 -


China Automatic Extrusion Blow Molding Machine

Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | Other, PE,PP,PS,PVC,PET | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Jiangsu, China | |
| Brand Name | medical tube making machine | Model Number | medical tube making machine | |
| Voltage | 220v or 380v | Power(W) | 37kw | |
| Dimension(L*W*H) | 3.8*2.2*2.8m | Weight | 8ton | |
| Certification | CE, ISO | Warranty | 1 year warranty | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
medical tube making machineenergy -efficient
high quality water extruding machine
deflashing device avail
medical tube making machine
Max. Product volume  | 7.5 liters  |
Output capacity  | 150~180pc/h  |
Screw diameter  | 75mm  |
Screw L/D ratio  | 24 L/D  |
Screw drive power  | 22 KW  |
Screw heating capacity  | 7 KW  |
No.of heating zone  | 4 zones  |
Output of HDPE  | 100KG/H  |
Oil pump drive power  | 11 KW  |
Clamping force  | 78KN  |
Max.size of mold  | 148-568mm  |
Mold stroke  | 400 X 450mm  |
Max.die diameter  | 160mm  |
Blowing pressure  | 0.6 mpa  |
Air Volume  | 0.8 M³/MIN  |
Cooling water pressure  | 0.3mpa  |
Water consumption  | 80 L/MIN  |
Size of Machine  | 3.8x2.2x2.8m  |
Weight of machine  | 8 ton  |
ABLB75Ⅱ5L PE blow moulding machine was specially designed for making plastic water bottles, lubricant oil bottles,detergent bottles ,cosmetic bottles, and other plastic containers not over 7.5L.
The features of this machine:
(1)It is suitable for producing PE,HDPE,PP, PVC,PETG,PS so on,plastic containers and bottles in all shapes are available,the duct volume is up to 7.5L.
(2)Double station single die head design,Stable and efficient.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Fully automatic process with low power consumption,high efficiency,quick and safe operation,easy for maintenance.
(5)Multiple screw available for double layer or tranparent liquid lever line.
(6)Auto deflashing device available,can remove the extra parts of bottles.
(7)Auto lubricant system controlled by PLC.
