Home > Products > 120L-220L jerry can blow molding machine > Extruding Machine for Blowing 220L Water Drums/pesticides Bottle Blow Moulding Machine
Extruding Machine for Blowing 220L Water Drums/pesticides Bottle Blow Moulding Machine
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Extruding Machine for Blowing 220L Water Drums/pesticides Bottle Making Machine
-
Automatic 120Liters Blow Molding/moulding Plastic Making Machine
-
Plastic Mannequin Blow Molding Machine
-
Plastic Mannequin Blow Moulding Machine
-
Plastic Mannequin Making Machine Mannequin Blow Molding Machine
-
Machines to Make Plastic Mannequin Blow Molding Machine
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | Other, PE,PP,PVC,PS,ABS and so on | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Jiangsu, China | |
| Brand Name | pesticides bottle blow moulding machine | Model Number | pesticides bottle blow moulding machine | |
| Voltage | 380v or 415v | Power(W) | 200kw | |
| Dimension(L*W*H) | 5.8*2.6*5.0m | Weight | 18ton | |
| Certification | CE,ISO,SGS | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
pesticides bottle blow moulding machineadvanced technology
good quality
competitive price
pesticides bottle blow moulding machine
Technical Parameters: ( ABLD120 )
Max. Product volume | 220 liters |
Output capacity | 30~40 pcs/h |
Screw diameter | 120mm |
Screw L/D ratio | 25 L/D |
Screw drive power | 45 KW |
Screw heating capacity | 20 KW |
No.of heating zone | 4 zones |
Output of HDPE | 160 KG/H |
Oil pump drive power | 37 KW |
Clamping force | 440 KN |
Max.size of mold | 800X1000mm |
Mold stroke | 500-1200mm |
Max.die diameter | 430mm |
Die heating power | 9.5 KW |
Die heating segments | 5 zones |
Blowing pressure | 0.8mpa |
Air volume | 1.2 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 100 L/MIN |
PAYMENT:
30% down payment paid at signing this contract by T/T , and the balance of 70% paid before shipment by T/T or irrevocable L/C.
Payment Info.
Advising bank: UAgricultural Bank of China, Suzhou Branch
Account No: 10525814040010761
Swift Code: ABOCCNBJ103
Beneficiary: Zhangjiagang Apollo Machinery Co., Ltd
DELIVERY:
Delivery no later than 25 days, after we received the deposit.
Packing:
Standard export packing for sea freight by 40’ CY
WARRANTY:
We warranty the quality of this machine for 12 months ,if there is any problem with the machine ,or any main parts are broken,we will repair it or replace new for free.
TRAINNING:
The seller should train two or three operating man for free. (Travel and hotel is by buyer’s expenses.)
