Made in China Hot Sale High Quality Plastic Bottle Blow Molding Machine
- shanghai or ningbo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Made in China Hot Sale High Quality Plastic Water Tank Making Machine
-
Pet Bottle ,pp Bottle, Pvc Bottle Making Machine/small Plastic Extruder
-
Pet Bottle ,pp Bottle, Pvc Bottle Making Machine/china Plastic Extruder
-
Pet Bottle ,pp Bottle, Pvc Bottle Making Machine/plastic Extruder Machine Sale
-
Pet Bottle ,pp Bottle, Pvc Bottle Making Machine/plastic Bottle Making Machine Used
-
4 GALLON PE Bottle Blowing Molding Machine/plastic Molding Machine
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PE | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Jiangsu, China | |
| Brand Name | plastic bottle blow molding machine | Model Number | plastic bottle blow molding machine | |
| Voltage | 220v or 380v | Power(W) | 205kw | |
| Dimension(L*W*H) | 5.8*2.6*5.0m | Weight | 18ton | |
| Certification | CE, ISO | Warranty | 1 year warranty | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
plastic bottle blow molding machine1 year warranty
deflashing device
competitive price
plastic bottle blow molding machine
more details of the machine:
Max. Product volume | 220 liters |
Output capacities | 18~25 pcs/h |
Screw diameter | 120mm |
Screw L/D ratio | 33 L/D |
Screw drive power | 145 KW |
Screw heating capacity | 30 KW |
No.of heating zone | 5 zones |
Output of HDPE | 250 KG/H |
Oil pump drive power | 30 KW |
Clamping force | 900 KN |
Max.size of mold | 1000X1600mm |
Mold stroke | 880-1700mm |
Max.die diameter | 520mm |
Die heating power | 12 KW |
Die heating segments | 5 zones |
Blowing pressure | 0.8mpa |
Air volume | 1.6 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 180 L/MIN |
package and deliver details
Certifications
some pics about the fair we have been abroad
ABLD120 automatic blow moulding machine was specially designed for making plastic water tanks,plastic cans, lubricant oil bottles,plastic drums, plastic toys and other plastic containers not over 220L.
The features of this machine:
(1)It is suitable for producing PE,HDPE,PP, PVC so on,plastic containers and bottles in all shapes are available,the duct volume is up to 160L.
(2)Single station single die head design,very easy to operate and maintenance.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Fully automatic process with low power consumption,high efficiency,quick and safe operation,easy for maintenance.
(5)Accumulation die head,MOOG parison controller equipped.
(6)Bottom blow technology make the product perfect.
(7)Auto lubricant system controlled by PLC.
