Single Crimping Tooling Aluminium Window Frame Making Machine
- Qingdao or any port of China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Aluminum Window Door Fabrication Machine / Single Head Crimping Machine
-
Aluminum Profile Window Corner Assembly Machine
-
Aluminium Window Machine / Single Head Corner Crimping Machine
-
Aluminum Door and Window Corner Assembling Fabrication Machine
-
Aluminum Single Head Corner Crimping Machine
-
Sliding Door Window Aluminum Corner Combining Machine
Product Details
| Brand Name | Better | Model Number | LZJ-03 |
Product Description
Single Crimping Tooling Aluminium Window Frame Making Machine,Model:LZJ-03
The machine is used for corner punching and riveting combination of aluminum profiles.crimping at 90 degree.The left and right crimping knives, driven by hydraulic system through a joint action device, feed synchronously, which guarantees the accuracy and strength of corner crimping and improve the quality of aluminum doors and windows greatly. Place a corner connector into the cavity of the two profiles before corner crimping, and the hydraulic crimping knives make permanently cold deformation on aluminum profile outer layers.Single head aluminum corner crimping machine is basic equipment for aluminum doors and windows, easy operate, economical and practical.
Operation air pressure | 0.5-0.8Mpa |
Air Consumption | 2L/min |
Power Supply | As required |
Motor power | 2.2kw |
Working air pressure | 0.4-0.6Mpa |
Contour dimension(L*W*H) | 1100*1000*1200mm |
Weight(about) | 400kg |
Cutting machine---Double head
Copy router milling machine
End milling machine
Corner connector cutting saw machine
Double / four corner combining machine
