Home > Products > New Products > 18sets Secondhand Japanses Tsudakoma ZW405 Water Jet Loom /on Sales
18sets Secondhand Japanses Tsudakoma ZW405 Water Jet Loom /on Sales
- Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
-
Model:ZAX9100 24 Sets New Tsudakoma Air Jet Loom
-
24 Sets New Tsudakoma ZAX9100 Air Jet Loom Hot Sale
-
On Sales:Model:ZAX9100 24 Sets New Tsudakoma Air Jet Loom
-
Tsudakoma ZAX9100 Air Jet Loom(hot Sale)
-
Tsudakoma ZAX9100 Air Jet Loom (Brand New)
-
Second Hand GA615 a 56-inch Dual-beam Vertical Transmission of Textile Machinery
Product Details
| Year | 1998-2002 | |||
| Place of Origin | Japan | Brand Name | Tsudakoma | |
| Model Number | ZW405 |
Product Description
18 sets Secondhand Japanese Tsudakoma ZW405 Water Jet Loom on sales
It is a professional improvement and innovative type. The system of let-off, shedding, take-up and driveline and the steady of whole machinery are all improved and optimized. With the ability of high speed and stable continuous operation, a wide range can be used, especially in petit and mid-density fabric. Electronic feeder or mechanical and cam shedding or dobby shedding can be installed on the machinery .
1. Easy electrocircuit is convenient to maintenance.
2.Use touch-screen that easy to operation.
3.Little noise and libration.
4.For promotion!!!!!!!!!!!!
Secondhand Tsudakoma ZW405 Water Jet Loom with good quality and runing steady.
Main Technical Parameters
| Particulars | Main Specifications |
| Nominal reed space(cm) | 135,190,210,230,260,280,340 cm |
| Connected electric power(kw) | 2.2kw 135cm-190cm or 2.8kw 210cm -340cm |
| Inching | Stop control in position and operation by stop button |
| Shedding | Cam shedding:10 heald frames maxDobby shedding:16 heald frames max |
| Let-off | Variable speed controller |
| Weft density | 5-60picks/cm |
| Beam flanges diameter(mm) | 600mm |
| Leno device | Planetary gear type with proximity switch |
| Drying | By suction blower device |
| Weft yarn cutting | By mechanical cutters on both sides of selvedges |
| Nozzle and needle | As your requirement |
| Rate of weft insertion | 2280m/min |
| Electric power source | 380v |
| Electric motors | 1.5kw 135cm-190cm & 2.2kw 210-340km |
| Mechanical speed | 1000RPM max (according to fabric) |
| Control panel | Logic & PC type |
| Indicator signal lamp | 4-colour LED type |
| Weight | 1.6 tons depending on reed space |
Picture Show

Please Feel Free To Contact Us:-)
Sales Manager:Mr. Steven Liu
Cellphone:0086-13773240991
Skype:jaky5188
Hotmail:milo.ceo
