Home > Products > Wool production equipment > Chinese FB801(1) Automatic Wool Reeling Machine,Yarn Reeling Machine
Chinese FB801(1) Automatic Wool Reeling Machine,Yarn Reeling Machine
- Shanghai
- T/T L/C D/P D/A
You May Like
Product Details
| Condition | New | Type | Other, Reeling Machine | |
| Place of Origin | Jiangsu, China | Brand Name | DACHENG | |
| Model Number | FB801(1) | Spinning Method | Ring Spinning | |
| Automatic | Yes | Certification | ISO9001/2000 |
Product Description
Specifications
1.OEM Available2.CE & ISO Certificate
3.High Quality
4.High Performance-price Ratio
5.High Yield
Details Of FB801 (1) Automatic Wool Reeling Machine:
FB801(1) Automatic Wool Reeling Machine
Characteristics:
+A formation system is attached respetively to dach upper part of the inner side of both left and right swift,which operates independently with swift for formation.
+The end breaking stop motion is controlled by light beams of a photocell .In case an end break occurs,t he flap drops down to black the light beams, and thus stops the machine.
+The rear door opens when taking down full hank while if closes for normal hank reeling.The swift can automatically stetch out to the required circumference.
+Egg-shaped gear drive is used for traverse, resulting eveness of hanks and better form of network.
Main specifications:
FB801(1)
No.of spindles | 60(double-side) |
Spindle gauge | 130mm(adjustable) |
Circumference of swift | 1600-2300mm |
Swift speed | 260,-300,360r/m |
Central height of swift | 700-730mm(adjustable) |
No. of inertia circles | 3-4 |
Travel of traverse guide | 70-110(adjustable) |
Overall dimensions | 5466*1850*1972mm(L*W*H) |
Machine weight | 2.4 t |
Picture Show
