PROCESSING MACHINE FOR SHORT FLAX FIBER, LONG RAMIE FIBER SPINNING
US$ 1 - 2
/ Set
1 Set(Min. Order)
- shanghai
- T/T L/C D/P D/A Credit Card
You May Like
-
FXLSeries Gill Box(flax,ramie,short Hemp Spinning)
-
FXL445 NSC Gill Box (Wool Spinning Machine)
-
Combing Machine For Short Flax,Long Ramie Fiber Spinning FX256
-
Textile Machine For Flax Spinning/Textile Machines For Sale
-
FBL313/FBL313Y Gill Box,Gilling MachineSpinning Machine For Wool Tops Making,Similar to NSC GC Series
-
Best Wool Spinning Machine,best Machine Similar to NSC GC,PB,GN6
Product Details
| Condition | New | Application | Short flax,long ramie fiber spinning | |
| Type | Gilling Machine | Place of Origin | Jiangsu, China | |
| Brand Name | dacheng | Model Number | FXL435 | |
| Spinning Method | Ring Spinning | Automatic | Yes | |
| Dimension(L*W*H) | 7098*1880*1981 (mm) | Certification | CE&ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Use:
With the sliver discharging speed reaching up to 250m/min and the front ratch being 39-63mm.Model FXL435 Chain Gilling Machine,Gill box is applicable to large batch flax(ramie)short hemp spinning process.
Technical process:
Combined combe-FXL315(giving-needle 1)-FXL325(giving needle 2)-FXL256(combing)-FXL415(needle 1)-FXL426(needle 2,with even-dressing)-FXL435(needle 3)-FX445(needle 4)-roving frame with twisting.
Hackling machine-FZ/FZL223(re-cutting-FZ/FZL314-FZ256(combing)-FZ/FZL415-FZ/FZL426-FZ/FZL435-FZ/FZL445,FZ473(roving).
Main parameters
| Item/Model | FXL435 |
| Giving-needle 3 | |
| Output slicer quantity (root) | 2 |
| Feed-in sliver quantity(root) | 2*5 |
| Feed-in sliver can's specification(mm) | Φ700*1000 |
| Output sliver can's spcification (mm) | Φ700*1000 |
| Maximum Feed-in weight (g/m) | 200 |
| Maximum output sliver weight (g/m) | 15 |
| Carding mode of the carding box | chain type |
| Special rod (diameter*head distance*pitch) | 9.525-3*72 |
| Needle bar qty (Block) | 72 both left and right sides |
| Needle bar specification(mm) | 332*13.5 |
| Needle density (Needle/cm) | 4.5 |
| Needle hitting times (times/min) | 5000 |
| Front roller sliver discharging speed (m/min) | 250(Normally open200) |
| Drafting multiple | 4.4-12.7 |
| Front roller spacing (mm) | 39-63 |
| Self-leveling apparatus | NO |
| Front roller specification (mm) | Φ62.5/Φ30 |
| Front leather roller specification(mm) | Φ80 |
| Rear roller specification (mm) | Φ62.5 |
| Rear pressurized leather roller specification(mm) | Φ80 |
| Front roller pressurized mode | pneumatic |
| Rear roller pressurized mode | pneumatic |
| Main electrical machinery power(kw) | 5.5 |
| Dust collecting motor's power(kw) | 3 |
| Frequency converter's specification | 3G3RV-A4055 |
| overall dimension (L*W*H)(mm) | 7098*1880*1981 |
