CD-1828I Automatic Wet Tissue Making and Packing Machine, Baby Wipe Machine

CD-1828I Automatic wet tissue making and packing machine,

baby wipe machine

1. Main technical parameter of making machine CD-180I

Power supply: 380V 50HZ

Power: 4KW

Suitable raw material: Spunlace non-woven fabric

GSM of raw material: 40-80g/m2

Size of raw material (mm): width 1000-1500, Φ1000

Production size(unfolded)(mm):(150-300mm)x(150-250mm) (L x W)

Production size(folded)(mm):(150-300mm)x(80-120mm) (L x W)

Production speed:80-150 stack/min(5 or 6 pcs / stack)

Folding way: "Z" folded (non-pop up)

Net weight of machine: about 1500kg

Water tank size(mm): 800x800x1900 (L x W x H)

Machine size(mm): 5500x3000x1800 (L x W x H)

Processing of production:

unrolling raw material – slitting web of raw material – folding into wipes – wetting wipes – cutting – output wet wipes.

Main technical parameter of packing machine CD-280

Power supply: 380V, 50HZ

Power: 6KW

Packing form: Pillow type

Production speed: 40--50packs/min

Product size (mm): (180-350)x(90-120)x(30-80) (L*W*H)

Control system: PLC control system, color touching screen

Net weight of machine: Approx. 1200KG

Machine size(mm): 5280*1000*2100mm (L*W*H)

Adopt PLC control, cutting as the length was set, working are more exact

Touching screen, the setting of parameter is convenient and fast, easier coperate

3 meters raw material conveying shelf

Electrical eye tracks automatically,

Date printing device,

Punching device,

Labeling device.

Adjustable bag-making equipment

With inserting corner device to make pillow type packing

2. The working process

Unrolling packing film—printing date—punching window hole on packing film— sticking label on window hole --- feeding wipes and forming bag — centre sealing---discharge air in the bag---end sealing and cutting—output finished products

3. Machine Introduction

The cover of machine and the parts which had touched with the wetting is made by stainless steel or stainless material, the machine is beautiful and the products is sanitary, wetting on line, it leads the product uniformly, auto-counting, for easier packing. It is easy to change the material, auto-stop when the material is use up.

By exporting standard protective measures. Such packing shall be suitable for long distance ocean and /or air, and inland transportation and well protected against dampness, moisture, shock, rust and rough handling so as to ensure that the goods will safely arrive at the erection or construction site without any damage.
