Product Details
| Condition | New | Product Type | Facial Tissue | |
| Processing Type | Cutting Machine | Place of Origin | Fujian, China | |
| Brand Name | CHUANGDA | Model Number | CDH-V-7L | |
| Voltage | 380V 50HZ | Power(W) | 9.2KW | |
| Dimension(L*W*H) | 6300*2900*1980MM | Weight | 4000KG | |
| Certification | CE | Warranty | One year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
CDH-V-7L V-fold hand towels machine,facial tissue machine
CDH-V-7L used PLC computer programming technology, variable frequency speed control, human-machine interface operating system; CVT transmission ratio before and after, to adapt to pull the paper to improve the uniformity of finished appearance.
1.Functions and Features
Configuration Pneumatic embossed steel to steel, pneumatic separator
Back pressure on the use of paper planes paper, non-polar ratio adjustment, adjusting the tension of base paper.
The use of Roots vacuum adsorption system, inspiratory capacity and stable operation.
Break automatic shutdown system, to avoid breaking free paper or paper waste generated.
The use of traction before and after the switch to move the base, operation is more simple and more secure.
2.Main Technical Parameter
Production Size | 200×200mm |
Parent Roll Size | 1200mm (other sizes are available) |
Paper Core Size | 76.2mm (other sizes are available) |
Production Speed | 0- 80 m/ min |
Control System | PLC Control System |
Embossing System | Steel to Steel
|
Cutting System | Pneumatic Cutting |
Drive System | Synchronous Belt, Nonpolar Gear-box |
Counting System | Printing ink |
Power System | 5.5 KW |
Vacuum System | 37 KW Roots Vacuum Pump |
Pneumatic System | 3 HP Air Compressor ≥5kg/cm Pa(prepared by customer) |
Machine Size | 6300×2900×1980mm (L×W×H) |
Net Weight of Machine | 4000 kg |
Specification of Material | 35- 38 g/m2 |
3. Pictures of our company:
4.Pictures of machine part:
