MS Angle Steel Bar, MS Angle
- TIANJIN CHINA
 - T/T

You May Like
Product Details
| Standard | ASTM, BS, DIN, GB, JIS | Dimensions | 20*20*2-200*200*18mm | |
| Grade | Q195-Q420 Series | Place of Origin | Hebei, China | |
| Brand Name | TIME | Model Number | 20*20*2-200*200*18mm | |
| Type | Equal | Application | ELECTRIC BUILDING AND TOWER |
Product Description
Steel Angle Bar
1. Material: SS400, ST37-2, A36, S235JRG1, Q235, Q345 etc.
2. Standard: GB/JIS/EN/ASTM/DIN and others.
3. Length: 6m, 9m, 12m or as your requirement
4. Payment: T/T, L/C
Picetures Of Products

The List Of Angle Size
| Equal angle bar | |||||||
| Size | Width (mm | Thicknessmm) | Density (kg/m) | Size | Width (mm | Thicknessmm) | Density (kg/m) |
| 20 | 20 | 3 | 0.889 | 80 | 80 | 7 | 8.525 |
| 20 | 20 | 4 | 1.145 | 80 | 80 | 8 | 9.658 |
| 25 | 25 | 3 | 1.124 | 80 | 80 | 10 | 11.874 |
| 25 | 25 | 4 | 1.459 | 90 | 90 | 6 | 8.35 |
| 30 | 30 | 3 | 1.373 | 90 | 90 | 7 | 9.656 |
| 30 | 30 | 4 | 1.786 | 90 | 90 | 8 | 10.946 |
| 35 | 35 | 3 | 1.578 | 90 | 90 | 10 | 13.476 |
| 35 | 35 | 4 | 2.072 | 90 | 90 | 12 | 15.94 |
| 35 | 35 | 5 | 2.551 | 100 | 100 | 6 | 9.366 |
| 40 | 40 | 3 | 1.852 | 100 | 100 | 7 | 10.83 |
| 40 | 40 | 4 | 2.422 | 100 | 100 | 8 | 10.276 |
| 40 | 40 | 5 | 1.976 | 100 | 100 | 10 | 15.12 |
| 44 | 44 | 3 | 2.002 | 100 | 100 | 12 | 17.898 |
| 44 | 44 | 4 | 2.638 | 100 | 100 | 14 | 20.611 |
| 38 | 38 | 3 | 1.719 | 100 | 100 | 16 | 23.257 |
| 38 | 38 | 4 | 2.261 | 110 | 110 | 7 | 11.928 |
| 48 | 48 | 3 | 2.19 | 110 | 110 | 8 | 13.532 |
| 48 | 48 | 4 | 2.889 | 110 | 110 | 10 | 16.69 |
| 48 | 48 | 5 | 3.572 | 110 | 110 | 12 | 19.782 |
| 50 | 50 | 3 | 2.332 | 110 | 110 | 14 | 22.809 |
| 50 | 50 | 4 | 3.059 | 125 | 125 | 8 | 15.504 |
| 50 | 50 | 5 | 3.77 | 125 | 125 | 10 | 19.133 |
| 50 | 50 | 6 | 4.465 | 125 | 125 | 12 | 22.692 |
| 56 | 56 | 3 | 2.624 | 125 | 125 | 14 | 26.193 |
| 56 | 56 | 4 | 3.446 | 140 | 140 | 10 | 21.488 |
| 56 | 56 | 5 | 4.251 | 140 | 140 | 12 | 25.522 |
| 56 | 56 | 6 | 6.568 | 140 | 140 | 14 | 29.49 |
| 63 | 63 | 4 | 3.907 | 140 | 140 | 16 | 33.393 |
| 63 | 63 | 5 | 4.822 | 160 | 160 | 10 | 24.724 |
| 63 | 63 | 6 | 5.721 | 160 | 160 | 12 | 29.391 |
| 63 | 63 | 8 | 7.469 | 160 | 160 | 14 | 33.987 |
| 63 | 63 | 10 | 9.151 | 160 | 160 | 16 | 38.518 |
| 70 | 70 | 4 | 4.372 | 180 | 180 | 12 | 33.159 |
| 70 | 70 | 5 | 5.397 | 180 | 180 | 14 | 35.383 |
| 70 | 70 | 6 | 6.406 | 180 | 180 | 16 | 43.452 |
| 70 | 70 | 7 | 7.398 | 180 | 180 | 18 | 48.634 |
| 70 | 70 | 8 | 8.373 | 200 | 200 | 14 | 42.894 |
| 75 | 75 | 5 | 5.818 | 200 | 200 | 16 | 48.56 |
| 75 | 75 | 6 | 6.905 | 200 | 200 | 18 | 54.501 |
| 75 | 75 | 7 | 7.976 | 200 | 200 | 20 | 60.056 |
| 75 | 75 | 8 | 9.03 | 200 | 200 | 22 | 71.168 |
| 75 | 75 | 10 | 11.089 | Length=6,9,12meters SS400 or Q235 | |||
| 80 | 80 | 5 | 6.211 | ||||
| 80 | 80 | 6 | 7.376 | ||||
Angle steel is a kind of steel which have two sides uprightness right angles section. It could be divided into equal and unequal shape. The kind which have two same uprightness border is equal angle. The kind one border longer than another is unequal angle. It is described by border width*width*thickness.
Usage: Be used in construction structure, communications steel tower, civil or agricultural machine makingalos, used in construction joist, tower, derrick etc.
Founded in 2003, we are a leading steel enterprise in China, located in Tangshan City, close to the west of Jing-Shen Expressway. with a steel factory with covers about 60.000 square meters,we employ apploximately more than 70 high quality talents and more than 200 specialized workness,since 2006,our sales network bestrow all over China mainland, Southeast Asiz,Middle East,Europe,South Korea,Etc.
Our main products include angle steel, channel, I-beam, H-beam, deformed bar, round bar, steel pipe, steel plate and more. Under the Operating Principle of "Compare service when they are in the same price, compare price when they offer the same service". we sincerely serve all customers from all over the world.
Any information on your market demand will be really appreciated. We will be happy to give you our best offer upon receipt of your detailed requirements, including the material,specification,quantity you need.
Jack Wang
Skype: Alvin66880
Wechat: WZLAN1
Tangshan Tianming Steel Co., Ltd
Address:Industrial Zone, Shaliuhe Town, Fengrun Dist., Tangshan, Hebei, China (Mainland)
