Home > Products > Inductive proximity sensor > BB-M4 Z8 series Ultra-mini inductive proximity sensor
BB-M4 Z8 series Ultra-mini inductive proximity sensor
USD $12.24 - $15.91
/ Piece
3 Pieces(Min.Order)
- 30000 Piece / Pieces per Month
- Beijing
- T/T
You May Like
-
BB-H4 Cable series Ultra-mini inductive proximity sensor
-
BB-H4 Z8 series Ultra-mini inductive proximity sensor
-
BB-H4 Plug series Ultra-mini inductive proximity sensor
-
BB-M5 Cable series Ultra-mini inductive proximity sensor
-
Q5x5 Cable series Flush mini inductive proximity sensor
-
Q5x5 pigtail series Flush ultra mini inductive proximity sensor
Product Details
| Place of Origin | Beijing, China | Brand Name | Bedook | |
| Model Number | BB-M40.6P-V11Z8 | Usage | Position Sensor | |
| Theory | Inductance Sensor | Output | Switching Transducer |
Product Description
Product Description
Features:
M4*0.5 mm, Stainless steel housing;
0.6mm, flush mountable;
DC 3-wire, switching output;
Cable & pigtail versions
Model No.:
| DC 3-wire 10-30V NPN N.O. | BB-M40.6N-V11Z8 |
| DC 3-wire 10-30V NPN N.C. | BB-M40.6N-V21Z8 |
| DC 3-wire 10-30V PNP N.O. | BB-M40.6P-V11Z8 |
| DC 3-wire 10-30V PNP N.C. | BB-M40.6P-V21Z8 |
Technical Data:
| Electrical data | Operating voltage | 10-30V DC |
| Switching Frenquency | 2000Hz | |
| Load current | 100mA | |
| No-load current | < 10mA (24 V) | |
| Voltage drop | ≤1.5V | |
| Hysteresis | <15%(Sr) | |
| Repeatability | <1.0%(Sr) | |
| Environment | Amibient temperature | -25...70℃ |
| Ingress protection | IP67 | |
| Mechanical data | Housing material | Stainless steel |
| Face material | POM | |
| Electrical connection | Connectors | M8 connector + PVC cable/0.3m; 3*0.14mm² |
| Accessories | Accessories | B8-3GV2/B8-3WV2 |
| (to be ordered separately) |
Packaging & Shipping
Packaging:
Standard export cartons: 11*8.5*5.5 cm/ 30*23*8cm/ 30*28*35cm/ 60*30*35cm
Shippping:
DHL International Economy Or according to the customer's requirements
Our Services
Service: pre-sale, sale and after-sale tracking service is comprehensive, The first-class technical R&D team and Double quality Testing one by one, providing technical support, complete and spotless quality guarantee.
