Home > Products > 2D Barcode Scanner > 2d Barcode Scanner Pdf417
2d Barcode Scanner Pdf417
Negotiable
/ Piece
1 Piece(Min. Order)
- Guangzhou
- T/T Credit Card PayPal
You May Like
-
Good Quality Handheld Barcode 2D Scanner 2D Pda Barcode Scanner
-
Supermarket QR Code Scanner 1D/2D Barcode Scanner With High Resolution
-
Supermarket 2D Handheld Qr Barcode Scanner With High Quality
-
China Industrial USB 2D Barcode Scanner QR Barcode Scanner USB Handheld 2D Scanner
-
Supermarket QR Barcode Reader USB Andoid Barcode Scanner 2D,Android 2D Barcode Scanner
-
CMOS Image Technology 2D Barcode Scanner QR Code Scanner QR Barcode Scanner
Product Details
| Place of Origin | Guangdong, China | Brand Name | Netum | |
| Model Number | NT-8099 |
Product Description
Specifications
1. COMS Tech Camera scan2. Support Graphics Format
3. 1D&2D all are competible
4. High resolution
2d Barcode Scanner Pdf417
Products details:
Features:
1. New design concept,make operation more comfortable.
2. Applying CMOS image technology, easy to scan.
3. Multiple dacode ability, fast to scan 1D/2D barcode and PDF417.
4. Best shape design, anti-knock and quakeproof.
5. Mulitple interface, support USB,RS232 port.
Parameters:
| 1 | Physical Characteristics | ||
| 1.1 | Dimensions: | 51mm x 30.61mm(width) x 21mm(height) | |
| 1.2 | Weight: | ||
| 1.3 | Voltage and Current: | 5 +/-10%VDC @ 350 mA | |
| 2 | Performance Characteristics | ||
| 2.1 | Light Source: | Aiming: 528 nm LED; illumination: 630 nm LED | |
| 2.2 | Field of View: | 34° V x 46° H(Vertical x Horizontal) | |
| 2.3 | Roll / Pitch / Yaw: | 360°, ±65°, ±60° | |
| 2.4 | Scan Performance: |
| |
| 3 | Symbology Decode Capability | ||
| 3.1 | 1-D: | UPC/EAN and with supplementals, Code 39, Code 39 Full ASCII, Tri-optic Code 39, RSS variants, UCC/EAN 128, Code 128, Code 128 Full ASCII, Code 93, Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5, MSI, Codell, IATA, Bookland EAN, Code 32 | |
| 3.2 | PDF417 (and Variants): | PDF417, microPDF417 and composite codes | |
| 3.3 | Postal: | U.S. Postnet and Planet, U.K., Japan, Australian, and Dutch | |
| 3.4 | 2-D: | MaxiCode, DataMatrix (ECC 200), and QR Code | |
| 3.5 | Print Contrast: | 25% minimum reflectance | |
| 3.6 | Motion Tolerances: | Horizontal velocity: 5 in. (12.7 cm) per second | |
| 3.7 | Interfaces Supported: | IE1100: RS-232C (Standard, Nixdorf, ICL, and Fujitsu); USB (Standard, IBM SurePOS, Macintosh) and Synapse connectivity allows for connectivity to all of the above plus many non-standard interfaces. | |
| 4 | Imaging Characteristics | ||
| 4.1 | Image (Pixels): | 0.35 Megapixel 752 pixels H x 480 pixels V | |
| 4.2 | Graphics Format Support: | Images can be exported as Bitmap, Jpeg, and Tiff | |
| 4.3 | Image Transfer Speed: | USB 1.1: Up to 12 Megabits/secondRS232: Up to 115 kb baud rate | |
| 4.4 | Image Transfer Time: | Typical USB application is ~ 0.2 seconds with a compressed Jpeg of 100 kb | |
| 5 | User Environment | ||
| 5.1 | Operating Temperature: | 32° to 122° F / 0° to 50° C | |
| 5.2 | Storage Temperature: | -40° to 158° F / -40° to 70° C | |
| 5.3 | Humidity: | 5% to 95%, non-condensing | |
| 5.4 | Drop/Shock Specifications: | Withstands 2000g to concrete | |
| 5.5 | Ambient Light Immunity: | Immune to normal artificial indoor and natural outdoor (direct sunlight) lighting. | |
