Product Details
Place of Origin | Guangdong, China | Brand Name | POWERLINK | |
Model Number | PDH-4E1-E |
Product Description
16E1+4*10/100/1000M PDH Fiber Optical Multiplexers Singlemode Dual Fiber 20KM 19 Inch Rack
220VAC and -48VDC Dual power supply OEM&ODM factory
PDH optical multiplexer is one of the most transmission equipment in point-point optical network. PDH multiplexer have perfect alarm function, data office telephone optional, high reliability and stabilization, low power consumption, high integration, small bulk, easy installation and maintenance.
PDH optical multiplexer provides 16 standard E1 interfaces together with one channel of order wire, with self-contained alarm and NM functions, as well as self-testing and E1 loop-back testing functions. Alarm signals are provided in a full range, including LOS,LOF,10-3 error code, and 10-6 error code alarms of line side as well as LOS and HDB3 coding violation alarms of E1 bypass, and available with sound alarming signals.
PowerlinkPDH multiplexer is popularly with telecommunication operator and suitable in business for communication operator, government and kinds of entities.
The Mini 4E1 PDH fiber optical multiplexer is a fiber media transport for 4 x G.703 E1 transmission. The BNC model provides unbalanced 75 Ohm coaxial connections while the RJ-45 model provides balanced 120 Ohm connections over twisted pair wiring. Special mini type version model can be used anywhere where space is limited, like outdoor boxes and cabinets, high equipment density populated areas and elsewhere!
Specifications
- Single mode dural optical port-4 channels of E1 ports
- Low power consumption
- ISO certification
- 1+1 fiber redandancy are provided
- Optional Power redundancy to ensure stable system
- Optional function of ALS and SNMP
Main Feature
- Provide 4E1 interface (120BG telephone channel)
- Provide function of 4E1 remote loop,fiber local loop,and 1 interface phone
- Optional power 1+1 to ensure stable system
- Two fiber two direction and single fiber two direction
- 1+1 power,orderwire phone and the ALS and SNMP are optinal,Please state the requirement when in order
- 4E1 PDH multiplexer realizes 1~4E1 transmission over fiber
- E1 spur track loop back testing features, easy to be installed and maintenance
- External dimensions: 19-inch rack (with distribution frames rack)
- Provide the 1+1 fiber back up
- Optical optional by customer 's requirement
E1 interface | 4E1 to 16E1 interface for 4E1 to 16E1 |
E1 rate: 2.048Mb/s±50ppm | |
Code type: HDB3 | |
E1 Style: Pinfet | |
E1 comply with ITU-T G.703 | |
Jitter compl y with ITU-T G.823 and G.742 | |
E 1 with DB37. Be ab le to be with 75Ω (BNC) or 120Ω (RJ45) by adaptor in the accessory | |
Fiber | Optical rate: 16.896Mbit/s |
optical style:1B1H | |
Default: dual fiber, single mode, 20km (40km optional) | |
connector: FC /SC | |
wavelength:1310nm | |
Receiver sensitivity:≤ -38dBm(BER ≤ 10-11) |
Power Requirements
- Power Input: AC /DC optional
- AC180V~240V
- DC-36V~DC-72V
- DC+20V~DC+36V
- Power Consumption: Working Environment
- Operating Temperature: 0°C ~+50°C
- Storage Temperature: -40°C ~+70 °C
- Packaging : bags&caron box
- Shipping: International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
- FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
- DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.
- "One to one" heart to heart service:Sales representative serve for five clients only. We look forward the continuing long-term services for you, but not just one or two times' co-operation.
- Perfect after-sales service :24-hour designated telephone number, e-mail and customer manager
