AOTECH Type C Usb3.1 Pci Express Card

Features

l         PCI Express (1-port Type C and 1-port Type A)

l         Compliant with Universal Serial Bus 3.1 specification Gen2

l         Compliant with USB Attached SCSI Protocol Revision 1.0

l         Compliant with xHCI (eXtensible Host Controller Interface) specifications Revision 1.1

l         Supports simultaneous operation of multiple USB 3.1, 3.0, USB 2.0 and USB 1.1 devices

l         Supports USB data transfer rate of 10G/5G/480M/12M/1.5M bps

l         Expands dual external USB3.1 Super-Speed plus Type-A ports on the system

l         Each USB port supplies maximum +5VDC / 900mA power output to USB device

l         Built-in over current protection on each USB port

l         Support device remote wakeup function from USB keyboard or mouse

l         Support Control, Bulk, Stream, Interrupt, Isochronous transfer type

l         Operation Temperature :0 to 60°C (32 to 140°F)

l         Storage Temperature:-20 to 70°C (-4 to 158°F)

l         Operation Humidity:5 to 95% RH

System Requirements

Windows 7 (X86/X64)

Windows 8.x / 10 (X86/X64) (Windows in-box driver)

Support Linux 2.6.31 or later (Linux OS already implemented USB3.0 driver)

Package Contents

1 × PCI Express to 2 ports USB3.1 Host Controller Card(Type C+Type A)

1 × User Manual

1 × Driver CD

1 x Low Profile Bracket

USB3.1 is launched! It is an enhanced version of USB3.0, supports transportation up to 10Gbps, supports 100W power supply and 4K UHD transportation. USB3.1 Type provides positive and negative plug functionality, it would be most fashionable that used for tablet, Mobile Phone, Hard Disk Drive, and so on
Product Introduce: this product can extend to USB3.1 type C with ultra highspeed data transmission, and it is compatible backward USB2.0 and USB1.1. The speed is faster double than USB3.0. It supports hot-swapping, specifically manufacturing for personal computers, consumer electronics and communications equipment to provide higher and faster speed.

Specifications

Hardware

USB Communication

Driver Support

Environment

 Welcome your OEM for the USB 3.1 Type C pci express card
