Home > Products > Arch Roof Roll Forming Machine > PRO Screw-joint Arch Roof Roll Forming Machine and Steel Sheet Forming Machine
PRO Screw-joint Arch Roof Roll Forming Machine and Steel Sheet Forming Machine
US$ 40,000 - 40,000
/ Set
1 Set(Min. Order)
- Dalian
- T/T
You May Like
-
PRO Bolt-joint Arch Sheet Forming Machine or Machinery
-
PRO Bolt Joint Arch Sheet Forming Machine (PRS-1000-680)
-
Yingkou PRO Screw-joint Arch Building Making Machine
-
Yingkou PRO Screw-joint Arch Building Making Machine/roll Form Machin
-
PRO Bolt-joint Arch Sheet Forming Machine or Roll Forming Machinery
-
PRO Screw-joint Arch Roof Roll Forming Machine and Project
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Steel | Use | Roof | |
| Place of Origin | Liaoning, China | Brand Name | PRO | |
| Model Number | PRS-1000-680 | Certification | CE | |
| Warranty | 13 Months | After-sales Service Provided | Overseas service center available |
Product Description
PRO Screw-joint arch roof roll forming machine and steel sheet forming machine
Technical Parameter:
- Dimension : 10000mm×1500mm×1500mm
- Weight : Around 8 T
- Shearing material : 12CrMoV
- Shearing type : Mechanical
- Total motor power : 25KW
- Main motor : 7.5KW
- Decoiler motor : 3.0KW
- Leveling machine motor : 4.0KW
- Shearing machine motor : 3.0KW
- Hydraulic station power : 7.5KW
- Roller Material : 45# high-quality steel (Standard), quenched HRC 55~65, hard chrome plating.
- Shaft Material : 45# high-quality steel, galvanized
- Stands of forming : 10
- Feeding width : 1000mm
- Effective width : 680mm
- Using rate : 68%
- Rolling thickness : 1.0-1.2mm
- Suitable Width : 4m-24m
- Decoiler : Load bearing: 8 T
