200kw Kaplan Water Turbine
- Chongqing
- T/T
You May Like
Product Details
| Place of Origin | Chongqing, China | Brand Name | Hi-Sea | |
| Model Number | Kaplan Turbine | |||
| Electricity Generator Type | Hydro Power | Output Voltage (V) | 400 |
Product Description
Specifications
water turbine:1.Power:125 to 6300KW
2.Head:10 to 150m
3.Runner diameter:0.5 to 1.0m
4.Frequency: 50Hz 60Hz
water turbine:
200kw Kaplan Water Turbine
Kaplan turbine(also called axial flow hydroturbine) is suitable for developing medium and low water head power resources. Kaplan turbine with both fixed blade and rotating blade can be provided. The turbine with fixed blade is mainly used for small hydropower station with medium and small capacity and small variation in load, while turbine with rotating blade is used for hydropower station with medium and big capacity and big variation in load.
This is technical parameters of 200kw kaplan turbine unit with runner diameter 0.8m and 1m. High quality and competitive price can be promised.
Hydraulic Turbine | Turbine Generator | Valve | ||||||
Runner Diameter(m) | Design Head(m) | Design Flow(m3/s) | Output(KW) | Speed(r/min) | Power(KW) | Voltage(V) | Efficiency(%) | Model |
1.0 | 7 | 3.60 | 220 | 333 | 200 | 400 | 90 | Φ1500 Butterfly Valve |
1.0 | 8 | 3.20 | 220 | 428 | 200 | 400 | 92 | Φ1400 Butterfly Valve |
0.8 | 9.5 | 2.65 | 220 | 500 | 200 | 400 | 90 | Φ1200 Butterfly Valve |
0.8 | 9.5 | 2.80 | 218 | 500 | 200 | 400 | 92 | Φ1250 Butterfly Valve |
200KW Kaplan Turbine
